Chapter 1: Installation; Rack Mounting Your Switchview 1000 Switch - Avocent SwitchView 1000 Installations- Und Bedienungsanleitung

NOTE: PS/2 and USB
interfaces cannot be used
simultaneously.
USB KVM
Connection
Figure 1.2: Basic SwitchView 1000 Switch Configuration
CAUTION: To reduce the risk of electric shock or damage to your equipment:
- Plug the power cord into a grounded (earthed) outlet that is easily accessible at
all times.
- Disconnect the power from the unit by unplugging the power cord from either the
electrical outlet or the unit.

Rack Mounting Your SwitchView 1000 Switch

Your SwitchView 1000 switch may be rack mounted using brackets.
Before installing the appliance, stabilize the rack in a permanent
location. Install your equipment starting at the bottom of the rack, then
work to the top.
CAUTION: Rack Loading - Overloading or uneven loading of racks may result in
shelf or rack failure, causing damage to equipment and possible personal injury.
Stabilize racks in a permanent location before loading begins. Mount components
beginning at the bottom of the rack, then work to the top. Do not exceed your rack
load rating.
PS/2 KVM
Connection
Power

Chapter 1: Installation

User
SwitchView 1000 Switch
Server
3
