Table 1.2: Main OSD Menu Functions (Continued)
Function
Setup
Logout
Figure 1.4: Setup Options Window
The following options will be selectable via the Setup OSD window.
Table 1.3: Setup menu functions
Function
Auto logout
OSD timeout
Autoscan period
Title bar
Hotkey
Setup Password
Load Default
Upgrade Firmware Upgrades the firmware of the switch.
Description
A submenu for various configurations.
Logs out keyboard and mouse for security.
Description
Specifies time for auto logout (0 to 99 min). Your
password must be configured and enabled for auto
logout to function.
Specifies duration for OSD menu to remain on screen.
Specifies time for the autoscan period.
Specifies the position of the OSD title bar.
Specifies the hotkey initiation sequence:
ScrLk (default), Caps Lock, ESC, F12 or
Num Lock.
Enter user-selectable password.
Loads the default settings.
Chapter 1: Installation 5
