(for reference of users and technicians)
TROUBLE
Ice Flake Machine
1. The voltage is lower than 187V.
does not work
2. The ambient temperature is too
Compressor
1. Refrigerant leaks
works, but no ice
2. Refrigerating system blocks.
was made
3. Solenoid valve opens constantly.
4. Condensing fan does not work.
5. Hall element has no interaction.
Compressor does
1. Water shortage.
not work
2. Ice full.
3. Compressor stops (the
The indicator of
1. Water shortage in water supply
water shortage
lights
2. Water valve damaged.
3. Tap water pressure too low.
The indicator of
1. Some ice has not dropped.
trouble lights
2. The water tank has not turned to
TROUBLE AND SHOOTING
CAUSE
low (lower than 10℃).
temperature of shell is too high).
system.
proper position.
CIRCUIT DIAGRAM
REMEDY
1. Turn off the machine, restart when the voltage
is normal.
2. Try again when the ambient temperature is
over 10 ℃.
1. Refill the refrigerant and test leakage.
2. Replace filter for the N
3. Replace the solenoid valve.
4. Check whether the condensing fan works.
5. Check whether the hall element is fine and in
proper position.
1. Check the water supply system (water valve and
water supply tube).
2. Take some ice out.
3. Turn off the machine and restart 1 hour later.
1. Check and make sure the water supply system
is fine, then restart.
2. Check the water valve.
3. If it is for tap water, the water pressure should
not be lower than 1KG/cm
1. Check whether the solenoid valve could be
open, if not, replace with a new one.
2. Check whether the switch (SQ1) could get
information from the rotation of the eccentric
wheel. Check whether the rotating motor and
eccentric wheel skid around. Check whether
the motor gear is damaged when rotate the
eccentric wheel by hand.
filling system.
2
2
.
6
