Operation Procedures; Maintenance - CombiSteel VDB-80S Gebrauchsanweisung

1. Unpack the package and take out the attached documents and spare parts such as the water inlet and
outlet tubes, ice shovel and gaskets, etc.
2. Position the ice maker on a well ventilated place and leave at least 150mm room between the ice maker
and the wall. Be sure the ice maker is positioned levelly and away from the heat source.
3. Make one end of the φ12 flexible plastic corrugated pipe (supplied with the machine) connected with
the water outlet tube on back of machine, another pipe end should be placed in a container for surplus
water (prepared by user himself) or in the sewer.
4. Make one end of the water inlet tube (supplied with the machine) connected with the 3/4"screw type
connector of the water tap so as to get the drinkable tap water. The water pressure of water supply pipe
2
is 1~8 Kg/cm . The other end of the water inlet tube should be connected with the screw type connector
of water valve on the back of the ice maker. Be sure to put gaskets (supplied with the machine) in both
ends of the water inlet tube before connecting. If it is an ice maker for purified water, a φ12 corrugated
pipe (supplied with the machine) should be used. Connect one end of the pipe with the purified water
supplier (cold water tap or end of water drainage tube of water dispenser) and another end with water
valve connector on the back of the ice maker. Make sure that the purified water outlet position is higher
than the top of the ice make.
5. Make power connection and press the switch on the panel, the run indicator light on. Then the maker
begins to work. All the procedures: water inlet ~ ice making ~ice dropping ~ ice storing, are controlled
automatically for ice making continuously. If ice is full in the ice storage container, the ice full indicator
on the display panel will light on and the ice maker will stop automatically; If there is a water shortage
or something wrong with the water supply system, the water shortage indicator will light on and the ice
maker will stop operation automatically.
6. For the ice maker use purified water as water source, if the water shortage indicator light and no ice is
made when start the ice making procedure, maybe there is air in the water inlet tube. Unplug one end
connecting water inlet tube and water valve of ice maker, then open water inlet switch till there is water
and air come from another end. Then connect the water inlet tube with water valve of ice flaker quickly.
1. If the compressor stops for any reasons like water shortage, too much ice, power off, etc., Don't restart
it right away. You can restart it 5 minutes later to protect compressor.
2. Check regularly the connectors of the water inlet and outlet tubes and drain the little surplus water that
may occur.
3. When not used for a long period. Remove all items from the compartment and disconnect the power
cord plug from the wall outlet. Clean the compartment interior and wipe away all water. Come away
the water supply pipe from the back of unit, and drain all water in it. To prevent mold formation and
bad smell, leave the door open to dry the compartment completely.
4. When plugging or unplugging, the plug should be held by hand and the wires
should not be dragged heavily.
5. Please clean the ice and its water supply system for one time every month. The
ice should be unplugged before cleaning.

OPERATION PROCEDURES

MAINTENANCE
