The barred bin symbol indicates that at the end of its service life
the product must be scrapped separately from other materials.
The manufacturer is responsible for separate scrapping of the
equipment at the end of its service life. The user must therefore
contact the manufacturer and follow the instructions given by the
latter for separate scrapping of the equipment at the end of its
service life.
Separate scrapping for subsequent recycling, treatment and
eco-compatible disposal contributes to avoiding negative effects
for the environment and for the health of persons, and promotes
the reuse/recycling of the materials of which the equipment is
fabricated.
Incorrect/illegal scrapping is punishable by law..
15. RESIDUAL RISKS AND SAFETY NOTICES
Although the sawing machine has been manufactured fully in compliance
with current regulations, residual risks exist that cannot be eliminated
and involve the use of appropriate individual protection devices. The
machine is equipped with notices to indicate the residual risks and how
to avoid them.
NOISE RISK
Ear protection must be worn
RISK OF INJURY TO THE HANDS
Safety gloves must be worn
RISK OF INJURY TO THE EYES
Eye protection must be worn
ABNORMAL USE RISK
Reading the manual before use is compulsory
Cutting with water is compulsory
DANGER OF CUTTING
DANGER OF ELECTROCUTION
DANGER: LASER BEAM
Please be reminded that checking the use of IPDs is delegated to the
employer.

16. TROUBLESHOOTING

- CAUTION!!! All maintenance operations must be performed
exclusively with the machine switched off, with the selector set to
"0" and the power plug disconnected from the mains.
IMER INTERNATIONAL S.p.A.
C 350 iPower
Trouble
The motor does not
start when the start
switch is pressed
Cooling water fails
to reach the blade
The blade does
not cut
* Operation to be carried out by an electrician
SILICA DUST WARNING
Grinding/cutting/drilling of masonry, concrete, metal and other materials with
silica in their composition my give off dut or mists cintainig crystalline silica.
Silica is a basic component of sand, quartz, brick clay, granite and numerous
other minerals and rocks. Repeated and/or substantial inhalation of airborne
crystalline silica can cause serious or fatal respiratory diseases, including sili-
cosis. In addition, California and some other authorities have listed respirable
crystallinesilica as a substance known to cause cancer. Whwn cutting such
materials, always follow respiratory precautions.
Use appropriate NIOSH-approved respiratory protection where dust hazard
may occur. Paper masks or surgical masks without a NIOSH approval number
are not recommended because they do little to protect the worker. For more
information about respirator programs, including what respirators have recei-
ved NIOSH approval as safe and effective, please visit the NIOSH website at:
http://www.cdc.gov/niosh/topics/respirators
Observe OSHA regulations for respirator use (29 C:F.R. § 1910.134).
Visit http://www.osha.gov for more information.
California proposition 65 message
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contain chemicals know (to the State of California) to
cause cancer, birth defects or other reproductive harm. Some examples of
these chemicals are:
-Lead, from lead-based paints
-Crystalline silica, from bricks and cement and other masonry products
-Arsenic and chromium, from chemically treated lumber
For further information , consult the following sources:
http://www.osha.gov/dsg/topics/silicacrystalline/index.html
http://www.cdc.gov/niosh/docs/96-112/
http://oehha.ca.gov/prop65/law/P65law72003.html
http://www.dir.ca.gov/Title8/sub4.html
http://www.P65warnings.ca.gov
Your risk from these exposures varies depending on how often you do this
typer of work. To reduce your exposure to these chemicals, work in a well-
ventilated area, and work with approved safety equipment, such as dust ma-
sks that are specially designed to filter out microscopic particles. Where use of
a dust extraction device is possible, it should be used. To achieve a high level
oof dust collection, use an industrial HEPA vacuum cleaner. Observe OSHA
29 CFR part 1926.57 and 1926.103
13
Causes Remedies
Current does not reach Check the line *
the supply line
The socket and plug Restore correct
are not connected connection
properly
The differential switch Turn the differential
is off switch on
The power cable from Change the cable *
the plug to the panel
is cut off
An electric wire inside Restore the connection *
the motor terminal strip
is cut off
An electric wire inside Change the switch *
the panel is cut off
The start switch is Change the switch *
faulty
Low water level in tank Restore the water level
Pump filter clogged Clean the pump filter
Current fails to reach Check the pump
the pump electrical supply *
Pump failure Change the pump *
Blade fitted in the Remove the blade
opposite direction to and reposition it in the
that of rotation direction shown on the
blade label
Worn blade Change the blade
