E N
Green signal light.
1
Hot water dispensing button.
2
Programmed co ee dose brewing button.
3
Manual co ee dose brewing button.
4
Steam dispensing knob.
5
Anomaly red ashing light.
6
Flashing: anomaly that can be solved by the
operator.
Steady on: anomaly that requires technical as-
sistance.
MACHINE STATUS
Heating
Machine ready (at temperature)
Co ee brewing (button 3)
Co ee brewing (button 4)
Co ee dose programming (button 3)
Co ee dose programming (button 4)
Co ee brewing start button pressed
with no capsule introduced
Lack of water in the tank
Hot water dispensing
Steam dispensing (until reaching
temperature)
Steam dispensing
Full used capsule drawer/drip tray,
bad positioning or missing
Extraction of the used capsule
drawer/drip tray not full
Opening capsule loading arm while
the machine is heating
Opening capsule loading arm when
the machine is ready (at tempera-
ture)
Energy saving
Faulty machine
= O = Flashing
12
CONTROLS AND SIGNALS
CONTROLS AND SIGNALS
1 2 3 4 5 6
= On = Sound
1
2
SOUNDS EVENTS
Tune.
1 sound when pressing the dispensing start and stop button.
1 sound when pressing the dispensing start and stop button.
3 sounds at the start and stop of programming.
3 sounds at the start and stop of programming.
3 sounds when pressing the dispensing start button.
3 sounds indicate the tank is empty.
1 sound indicates the tank is filled /refilled.
1 sound when pressing the dispensing start and stop button.
Repeated sound sequence until the machine is ready (at tempera-
ture).
1 sound when pressing the dispensing start and stop button.
3 sounds indicate the drawer is full.
1 sound at the insertion of the empty drawer.
3 sounds at the extraction of the drawer.
1 sound at the insertion of the not full drawer.
1 sound when opening and closing the capsule loading arm.
1 sound when opening and closing the capsule loading arm.
The machine passes on energy saving mode after about 30' of
inactivity. Tune after each pressure of any button or when lifting the
capsule loading arm to restart the machine.
Continuous sound for 40 seconds.
The sound is repeated if a dispensing button is pressed.
= Tune
EN
4
6
5
3
= Blink = Fade
