MobileMapper Pro
offers general mapping
and asset manage-
ment functions com-
bined with the powerful
navigation capabilities
of a recreational hand-
held GPS
Battery Life
You can expect up to
16 operating hours
with the backlight
turned off. Using the
backlight will shorten
the battery life signifi-
cantly. With the back-
light on continuously,
you can expect up to 8
hours of usage from
your two AA batteries.

1. Introduction

Thank you for buying a MobileMapper Pro from Magellan.

What is MobileMapper Pro?

MobileMapper Pro is a handheld navigation and positioning
system that enables you to describe the features being
mapped and then format and upload the data to a GIS. It of-
fers an easy-to-use and easy-to-deploy solution for general
mapping and for asset management.
MobileMapper Pro combines all the navigation capabilities of
a recreational handheld with feature attributing software to
support GIS data collection in the field and data display and
export in the office.

SD Card and Batteries

You will find the SD card and the two AA batteries inside the
MobileMapper Pro box. To install the SD card and then the
batteries, do the following:
- Slide the two tabs on the
back of the receiver to the
left and remove the bat-
tery compartment door.
- Take the SD card out of
its box by pulling the flap
open and then hold the
SD card with two fingers
with the label facing you.
- Place the top of the SD
card in the channel pro-
vided in the battery compartment.
- Carefully push the SD card towards the top of the unit
until you feel it lock into place. Do not force the SD card.
SD Card
1
