WARNINGS
Keep away from children or people with mental disabilities.
f f
the device contains small pieces that can be swallowed.
In order to prevent any risk of strangulation, please keep
f f
the electrodes wires away from children.
the device is meant for personal use. For reasons of
f f
hygiene, the electrode should only be used on one person.
Do not use the device by driving or by working on a
f f
machine.
Do not use this electro stimulation unit in a damp
f f
environment, a bathroom, a sauna or close to electric
machinery connected to mains and earthed, or even
piping earthed.
Use this device in a clean place (without dust nor dirt...).
f f
the simultaneous connection of a patient to a high
f f
frequency surgical unit may cause burns at the points of
contact of the stimulator's electrodes and the stimulator
may be damaged.
Operation in close proximity of a short wave therapy unit
f f
may cause instability in the stimulator's output power.
Do not, under any circumstances, attempt to open or
f f
repair the Multisportpro yourself! Only have repairs carried
out by the customer service department.
V. TEChNICAL SPECIFICATIONS
BELT
References : CtBB2MEAV2
Size (unisex) : from 34 to 60
Length of the unfolded belt :122 cm
Fabric : 35% sponge, 20% elastic
fabric, 15% polyester, 15% nylon, 10%
PVC + copper, 2% rubber, 3% non-
woven fabric
UNIT
Class IIa medical device in accordance with Directive 93/42/CEE
Software version
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
type of current
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Number of programs
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Number of program variations (or phases)
Number of adjustable independent outputs
Maximum intensity on a 500 Ω load/channel
Frequency range
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pulse width range
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power supply
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
- USEr MANUAL
TROUBLE SHOOTING
If your device doesn't work properly, do not use it and contact
your reseller.
PRECAUTIONS OF USE
Do not use the unit on your face.
f f
Do not leave within reach of children.
f f
Ask for advice from your physician:
if you have electronic or metallic implants (pins...),
f f
in case of skin condition (wounds...).
f f
On the heart area.
f f
If you carry a pacemaker.
f f
If you are pregnant.
f f
During first 6 weeks after baby birth.
f f
In case of neuromuscular diseases.
f f
In case of hemorrhagic diseases.
f f
On the face and skull.
f f
RECOMMENDATIONS FOR MAINTAINING
AND CLEANING
Clean the unit with a tissue dampened with a disinfecting
solution diluted with water at 1/10
ADHESIVE ELECTRODES
Reference : EASF110x71
Contact area : 67.5 x 47 mm (x2)
Estimated life expectancy : 40 uses
Class I medical device (Directive
93/42/CEE)
Adhesive, hydrophilic and
hypoallergenic electrodes
Please order new compatible
adhesive electrodes on www.sport-
elec.com.
E
Dual phase
88 "SPOrt" programs - 6 "HEALtH" programs
344
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0.25 to 160 Hz
70 to 360 μs
LiPo rechargeable battery 3.7 V - 1020 mAh
CONTRA-INDICATIONS
Do not use SPORT-ELEC®:
.
th
AC ADAPTOR
Reference : MN-A403-E120
Input : 100-240V, 50/60Hz, 0.25 A max
Output : 5V
the adapter is part of the equipment.
Only use the AC adaptor supplied
with the device.
Please replace this adaptor should it
fail (contact SPOrt-ELEC® or order at
www.sport-elec.com).
100 mA / 500 Ω / channel
0.6A
17
