1.4 Instructions for removable battery pack in
frame
1.4.1 Positioning the battery
pack
1. Remove the key from the lock.
2. Place the battery pack (A) in the frame.
Please make sure that the contact
points (B) are well connected.
3. Push the battery pack (B) carefully in
the frame.
4. Push the handle (C) down.
5. Check whether the battery pack has
been positioned correctly by pulling
the lever shortly. A correct positioned
battery pack cannot be removed any
more without the key (A).
61
A
C
61
B
B
A
B
A
B
