Controls
Tools 1
SHARPNESS : This function is digitally capable to keep crisp image at any timings. It is continuously
adjustable to get distinct image or soft one as you prefer, and set independently by different timings.
The number of adjustment steps is different depending on whether EXPANSION Mode is OFF, FULL
or ASPECT (1280 x 1024 is OFF Mode).
EXPANSION MODE : Sets the zoom method.
FULL : The image is expanded to 1280 x 1024, regardless of the resolution.
ASPECT : The image is expanded without changing the aspect ratio.
OFF : The image is not expanded.
CUSTOM (Digital input and Resolution of 1280 x 1024 only) :
Select one of seven expansion rates. In this mode the resolution may be low and there may
be blank areas. This mode is for use with special video cards.
VIDEO DETECT : Selects the method of video detection when more than one computer is connected.
FIRST DETECT : The video input has to be switched to "FIRST DETECT" mode.
LAST DETECT : The video input has to be switched to the "LAST DETECT" mode.
NONE : The Monitor will not search the other video input port unless the monitor is turned on.
DVI SELECTION : This function selects the DVI input mode(Input 1). When the DVI selection has been
change, you must restart your computer.
OFF TIMER : Monitor will automatically power-down when the end user has selected a pre-determined
amount of time.
Tools 2
LANGUAGE : OSM
OSM POSITION : You can choose where you would like the OSM control image to appear on
your screen. Selecting OSM Location allows you to manually adjust the position of the OSM
control menu left, right, down or up.
OSM TURN OFF : The OSM control menu will stay on as long as it is use. In the OSM Turn Off
submenu, you can select how long the monitor waits after the last touch of a button to shut off the
OSM control menu. The preset choices are 10, 20, 30, 45, 60 and 120 seconds.
OSM LOCK OUT : This control completely locks out access to all OSM control functions. When
attempting to activate OSM controls while in the Lock Out mode, a screen will appear indicating the
OSM controls are locked out. To activate the OSM Lock Out function, press SELECT, then + key and
hold down simultaneously. To de-activate the OSM Lock Out, press SELECT, then + key and hold
down simultaneously.
OSM ROTATION : To rotate OSM between Lnadscape and Portrait modes.
RESOLUTION NOTIFIER : This optimal resolution is 1280 x 1024. If ON is selected, a message
will appear on the screen after 30 seconds, notifying you that the resolution is not at 1280 x 1024.
HOT KEY : You can adjust the brightness and contrast directly.
FACTORY PRESET : Selecting Factory Preset allows you to reset all OSM control settings back to
the factory settings. Individual settings can be reset by highlighting the control to be reset and
pressing the RESET button.
*
LCD1880SX_QS.P65
® * control menus are available in seven languages.
: Trademarks apply to appropriate countries.
