Controls

OSM ® * (On-Screen Manager) control buttons on the front of the monitor function as follows:
To access OSM menu, press any of the control buttons (
To change signal input, press the SELECT button.
NOTE : OSM must be closed in order to change signal input.
EXIT
CONTROL
ADJUST –/+
SELECT
RESET
NOTE : When RESET is pressed in the main and sub-menu, a warning window will appear allowing you to
cancel the RESET function by pressing the EXIT button.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO ADJUST CONTRAST (Analog input only)
Adjusts the image displayed for non-standard video inputs.
AUTO BRIGHTNESS (Analog input only)
This function adjusts the brightness automaticaly for the best CONTRAST and BRIGHTNESS setting
based on the white display area.
Auto Adjust (Analog input only)
Automatically adjusts the Image Position and H. Size settings and Fine settings.
Position Controls
LEFT / RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN / UP
Controls Vertical Image Position within the display area of the LCD.
H.SIZE (Analog input only)
Adjusts the horizontal size by increasing or decreasing this setting.
FINE (Analog input only)
Improves focus, clarity and image stability by increasing or decreasing this setting.
AUTO FINE (Analog input only)
This function automatically and periodically adjusts the "FINE" setting for change in signal condition.
This function adjusts approximately every 33 minutes or when a change in signal timing is detected.
AccuColor
AccuColor Control Systems: Six color presets select the desired color setting. Color temperature
increases or decreases in each preset. (NATIVE color preset cannot be changed.)
NATIVE : Original color presented by the LCD panel that is unadjustable.
*
LCD1880SX_QS.P65
Menu
Exits the OSM controls.
Exits to the OSM main menu.
Moves the highlighted area left/right to select control menus.
/
Moves the highlighted area up/down to select one of the controls.
Moves the bar left/right to increase or decrease the adjustment.
Active Auto Adjust function. Enter the OSM controls. Enter the OSM sub menu.
Resets the highlighted control menu to the factory setting.
* Control Systems (Color Control Systems)
®
: Trademarks apply to appropriate countries.
