Quick Start
Remove Monitor Stand for Mounting
To prepare the monitor for alternate mounting purposes:
1. Disconnect all cables.
2. Place hands on each side of the monitor and lift up to the highest position.
3. Place monitor face down on a non-abrasive surface. (Place the screen on a 45 mm / 1.8 inch
platform so that the stand is parallel with the surface.) (Figure S.1)
4. Remove the 4 screws connecting the monitor to the stand and lift off the stand assembly (Figure S.2).
The monitor is now ready for mounting in an alternate manner.
5. Reverse this process to reattach stand.
NOTE : Use only VESA-compatible alternative mounting method. (100mm pitch)
Caution : Please use the attached screws (4 pcs) when mounting. To fulfil the safety requirements the monitor
must be mounted to an arm which guaranties the necessary stability under consideration of the
weight of the monitor. The LCD monitor shall only be used with an approved arm (e.g. GS mark).
