ASSEMBLY
BLADE GUARD (Fig. 5)
Attach the blade guard to the mounting bracket (26);
install the four screws (M5 x 16) from the bottom of
the blade guard through the mounting plate and into
the mounting bracket.
Using the screwdriver supplied, tighten all four screws
securely.
Note: When using the string head (12), the string
shield must be attached to blade guard.
GRASS DEFLECTOR (Fig. 15)
Attach the grass deflector (14) to the blade guard by
placing the two locking tabs (16) into the two notches
(17).
Using the screwdriver supplied, tighten the screw
securely.
WARNING
Always stop the engine and remove the spark
plug wire before making any adjustments such
as changing cutting heads; this is to reduce the
risk of serious personal injury.
CONVERTING FROM BRUSHCUTTER TO LINE
TRIMMER
REMOVING THE BLADE (Fig. 7)
Place the M6 wrench (1) through the hole of the gear
case (2) and the hole in the upper flange washer (3).
Turn the blade nut (9) clockwise by using the larger
end of the spark plug wrench (11) to remove.
Remove the washer (8), blade cover (5), cupped
washer (7), blade (6) and upper flange washer (4).
Retain the upper flange washer and cupped washer
for string head installation.
Attach the grass deflector (14) to the blade guard by
placing the 2 locking tabs into the two notches and
tighten the grass deflector screw by the screw driver
on the spark plug wrench.
NOTE: Store the brushcutter parts together for later
use.
INSTALLING THE STRING HEAD (Fig. 6)
Place the upper flange washer over the gear shaft
with the hollow side toward the gear head.
Install the cupped washer with the raised center away
from the upper flange washer.
Place the M6 wrench through the hole of the gear
case and the hole in the upper flange washer. Install
the smaller end of the connector (13) to the gear head
I
P
NL
S
DK
N
FIN GR HU
CZ RU
English
by turning counterclockwise. Tighten securely.
With the M6 wrench in place, turn the string head (12)
counterclockwise onto the larger end of the connector
to install. Tighten securely.
CONVERTING FROM LINE TRIMMER TO
BRUSHCUTTER
REMOVING THE STRING HEAD (Fig. 6)
Place the M6 wrench through the hole of the gear
case and the hole in the upper flange washer.
Remove the string head by turning clockwise.
With the M6 wrench in place, turn the connector
clockwise to remove.
Remove the cupped washer and upper flange washer.
Retain them for blade installation.
Loosen the screw on the grass deflector. Remove the
grass deflector by pushing in on the two locking tabs
while pulling on the grass deflector to separate from
the blade guard.
NOTE: Store the string head and grass deflector
parts together for later use.
INSTALLING THE BLADE (Fig. 7)
Place the upper flange washer over the gear shaft
with the hollow side toward the gear head.
Center the blade on the upper flange, making sure
the blade sits flat. Install the cupped washer with the
raised center away from the blade.
Place the blade cover and washer on top.
Install the blade nut by turning counterclockwise.
Place the M6 wrench through the hole of the gear
case and the hole in the upper flange washer. Tighten
the blade nut securely with the larger end of the spark
plug wrench.
OPERATION
FUEL AND REFUELING
HANDLING THE FUEL SAFELY
Always handle fuel with care, it is highly flammable.
Always refuel outdoors where there are no sparks
and flames. Do not inhale fuel vapors.
23
RO PL SLO HR TR EST LT
Read the operation manual and follow all
warnings and safety instructions.
Wear eye protection and ear protection.
Keep all bystanders, especially children and
pets, at least 15 m from the operating area.
