A BEGINNER'S GUIDE TO COMPRESSION

Compressors are probably the most widely used signal processors in the audio industry.
A compressor can be thought of as an automatic volume control. Once the volume of
the signal exceeds a certain level (called the 'threshold'), the compressor reduces the
gain (or, in other words, 'turns the volume down'), causing the signal to be less loud
than it would otherwise have been.
The amount by which the compressor reduces the gain is determined by the 'ratio'.
The ratio is conventionally expressed as a numerical value, e.g. '4:1', which represents
the amount by which the gain is reduced when the volume of the signal rises above
the threshold.
Let's take an example with some real numbers. If the threshold is set to –10 dB and the
ratio is set to 4:1, any signal whose level exceeds –10 dB needs to rise in level by 4 dB
for the output of the compressor to rise by 1 dB. Therefore an input signal with a peak
at –6 dB (which is 4 dB above the threshold) would emerge from the compressor with
a peak at –9 dB (1 dB above the threshold). Signal levels below the threshold are
unaffected, so if the signal in the above example varied between –20 dB and –6 dB
before entering the compressor, it will vary between –20 and –9 dB after being
compressed – its dynamic range (the difference between the quietest and loudest parts
of the signal in dB) is reduced from 14 dB to 11 dB.
Compression has the result that any variations in the volume of the signal (in other
words, the signal's dynamic range) are reduced – the amount of this reduction is
determined by the threshold (the level above which the gain is reduced) and the ratio
(the amount by which the gain is reduced.) Higher ratios are referred to as hard ratios;
lower ratios are called soft ratios.
Because compression causes a reduction in volume level of loud signals, gain must be
applied after the compressor to bring the overall volume level back up, so that the
maximum volume before the compressor is the same as that after the compressor. This
is called 'make-up gain', and is necessary so that the maximum level of the signal is
always the same, for correct level matching with any further processing or other
equipment.
Once 'make-up gain' has been applied, the part of the signal that was lower than the
threshold volume (and hence not compressed) will now be louder than it was before
the compressor. This will cause any compressed instrument to sound louder. One use
for this phenomenon is to give guitars more sustain.
In most pop music, the backing instruments (such as drums, bass guitars, rhythm
guitars etc) tend to be compressed heavily (using a fairly hard ratio and low threshold),
so that they remain at a consistent volume level throughout the track. This will
provide a solid backing, without occasional drum hits or bass notes poking through (or
disappearing from) the mix untidily.
A soft ratio tends to be used on instruments such as lead guitars or vocals that 'sit' on
top of the mix. In this situation it is often desirable to preserve more of the dynamics
of the original performance, to retain more expression. A reduction in variation of
volume level is still required (for the reasons mentioned above), but not to the same
extent.
Visit www.focusrite.com for further information and a comprehensive 'Guide to Compression'.
