Parts Reference

Übersicht aller Teile
Z082 x2
Flat Head Screw M3x8mm
Senkkopfschraube
Vis tête plate
Tornillo avellanado
Z083 x13
Flat Head Screw M3x10mm
Senkkopfschraube
Vis tête plate
Tornillo avellanado
Z084 x2
Flat Head Screw M3x12mm
Senkkopfschraube
Vis tête plate
Tornillo avellanado
Z085 x2
Flat Head Screw M3x15mm
Senkkopfschraube
Vis tête plate
Tornillo avellanado
Z086 x2
Flat Head Screw M3x18mm
Senkkopfschraube
Vis tête plate
Tornillo avellanado
Z449 x6
Flat Head Screw M2.5x12mm
Senkkopfschraube
Vis tête plate
Tornillo avellanado
94554 x4
Button Head Screw M4x10mm
Flachkopfschraube
Vis tête ronde
Tornillo cabeza redonda
Z216 x4
Button Head Screw M3x15mm
Flachkopfschraube
Vis tête ronde
Tornillo cabeza redonda
Z350 x4
Button Head Screw M3x5mm
Flachkopfschraube
Vis tête ronde
Tornillo cabeza redonda
Z352 x27
Button Head Screw M3x8mm
Flachkopfschraube
Vis tête ronde
Tornillo cabeza redonda
Z353 x2
Button Head Screw M3x10mm
Flachkopfschraube
Vis tête ronde
Tornillo cabeza redonda
Z354 x9
Button Head Screw M3x12mm
Flachkopfschraube
Vis tête ronde
Tornillo cabeza redonda
Référence des pièces
Referencia piezas
Z356 x2
Button Head Screw M3x18mm
Flachkopfschraube
Vis tête ronde
Tornillo cabeza redonda
Z357 x2
Button Head Screw M3x20mm
Flachkopfschraube
Vis tête ronde
Tornillo cabeza redonda
Z411 x2
Cap Head Screw M2x8mm
Inbusschraube
Vis tête cylindrique
Tornillo cabeza cilíndrica
Z538 x4
Cap Head Screw M3x25mm
Inbusschraube
Vis tête cylindrique
Tornillo cabeza cilíndrica
Z541 x1
Cap Head Screw M3x6mm
Inbusschraube
Vis tête cylindrique
Tornillo cabeza cilíndrica
Z543 x9
Cap Head Screw M3x10mm
Inbusschraube
Vis tête cylindrique
Tornillo cabeza cilíndrica
Z544 x8
Cap Head Screw M3x12mm
Inbusschraube
Vis tête cylindrique
Tornillo cabeza cilíndrica
Z545 x4
Cap Head Screw M3x15mm
Inbusschraube
Vis tête cylindrique
Tornillo cabeza cilíndrica
86895 x4
Cap Head Screw M3x30mm
Inbusschraube
Vis tête cylindrique
Tornillo cabeza cilíndrica
86094 x4
Screw Shaft M4x2x12mm
Gewindestift
Axe fileté
Eje roscado
Z242 x2
E Clip E2mm
E-Clip
Circlips
Circlips
Z244 x5
E Clip E4mm
E-Clip
Circlips
Circlips
29
Z700 x1
Set Screw M3x3mm
Madenschraube
Vis sans tête
Tornillo sin cabeza
Z705 x1
Set Screw M3x10mm
Madenschraube
Vis sans tête
Tornillo sin cabeza
Z713 x1
Set Screw M3x30mm
Madenschraube
Vis sans tête
Tornillo sin cabeza
6121 x2
Body Pin (Small)
Karosseriesplinte Klein
Clip carrosserie (Petit)
Clip carrocería (pequeño)
75106 x6
Body Clip (6mm)
Karosserieklammern (6mm)
Clip carrosserie (6mm)
Clip carrocería (6mm)
Z224 x15
Washer 3x8x0.5mm
Scheibe
Rondelle
Arandela
Z685 x8
Washer 3x8x0.5mm
Scheibe
Rondelle
Arandela
Z694 x5
Washer 5x10x0.5mm
Scheibe
Rondelle
Arandela
86896 x8
Ball Stud 4.8x12mm
Kugelkopf
Rotule sur tige
Rotula con eje
86897 x6
Ball Stud 4.8x15mm
Kugelkopf
Rotule sur tige
Rotula con eje
A249 x1
Ball M2x3.8x4.5mm
Kugel
Billes
Bola
Z264 x7
Pin 2x10mm
Pin
Broche
Pasador
Z653 x6
Nut M3
Mutter
Ecrou
Tuerca
Z661 x4
Lock Nut M2.6
Stoppmutter
Ecrou nylstop
Tuerca autoblocante
Z663 x10
Lock Nut M3
Stoppmutter
Ecrou nylstop
Tuerca autoblocante
Z684 x4
Flanged Lock Nut M4
Stoppmutter
Ecrou
Tuerca M4
A838 x4
Flange Pipe 3x4.5x5.5mm
Metallhuelse
Palier
Casquillo
6819 x10
Silicone O-ring P-3 Red
Silikon O-Ring P-3 Rot
Joint torique silicone P-3 Rouge
Junta torica silicona P3 roja
6897 x2
O-Ring P4
O-Ring P4
Joint torique P4
Junta torica P4
86883 x4
Rubber Bump Stop 3x7x4mm
Einfederweg Begrenzer
Butee caoutchouc
Arandela goma
87511 x4
Servo Grommet
Servohuelsen
Jeu oeillet de servo
Torica servo
86898 x2
X-Ring 1.8x5mm
X-Ring
Joint section X
Junta sección x
86029 x4
Shock Diaphragm 13x4mm
Daempfermembran
Membrane amortisseur
Membrana amortiguador
