SECTION 2
2.1 Introduction
2.2 General Specifi cations
EPP-200 Power Console (0558004315):
OUTPUT (100% duty cycle)
Voltage ......................................................................................................... 160VDC
Current range DC ................................................................................. 50A to 200A
Power ................................................................................................. 8000 W to 32000 W
Open Circuit Voltage (OCV) .................................................................. 325VDC
INPUT
Voltage (3-phase) .............................................................. 200/230/380/415/460/575 Volts
Current (3-phase) ...............................................................115/100/60/55/50/40 Amperes
Frequency ....................................................................................................50/60Hz
KVA ................................................................................................................. 39.8 kW
Power ............................................................................................................. 37.8 kW
Power Factor ...................................................................................................95%
Input Fuse .................................................................................. See Section 3, Installation
The EPP-200 Power Console is designed for mechanized plasma
applications. It can be used with other ESAB products such as the
PT-24 and PT-600 torches, an optional plumbing box and a remote
set-up pendant.
• 50 to 200 Amperes cutting current range
• Forced air cooled
• Solid state DC power
• Integral water cooler
• Input voltage protection
• Local or remote front panel control
• Thermal switch protection for main transformer and
power semiconductor components
• LED status troubleshooting
83
DESCRIPTION
