e. The Home Mode Function
When a sensor signal is triggered, you will be able to monitor the zone on the LCD. The main unit will also emit a
chime. This function allows you to able or to disable a zone.
1. To activate the home mode, press HOME. You will hear a chime and see a HOME icon on the LCD.
2. Wait 60 seconds until you hear a beep.
3. When the sensor detects a signal in the protected area, you will hear a chime.
4. Press HOME to exit the mode.
5. The system has all the zones factory enabled. To disable a zone, enter the access code and press HOME.
6. The ZONE 1 icon will now flash. Use UP or DOWN to select the zone and press ARM/DISARM to confirm your
selection. Next, press ON or OFF to enable or to disable the zone. Press ARM/DISARM to confirm.
7. Press HOME again to exit the mode.
f. Other Functions
1. The HAM1000WS features a LED indicating when the battery is low. When this LED is flashing, please
replace the battery with a fresh one to ensure proper operation.
2. In standby mode, press DOWN to view the last 5 triggered records.
8. The Motion Detector (order code HAM1000WS/MDS, incl.)
a. Testing the Motion Detector
Before mounting the motion detector, it is recommended to test the transmitting range. Press HOME on the main
unit and align the motion detector to cover a large area. Temporarily fix the motion detector and walk by to test
the sensor. You should hear a chime coming from the main unit. If not, realign the motion detector.
b. Installation
1. Open the battery compartment and install 1 alkaline 9V battery
(order code 6LR61, not incl.). Close the battery compartment.
2. Choose a suitable location, at a height of 1.5 to 2m (5 to 6
feet). Drill the holes, install the plugs and fix the mounting
bracket using the screws. Slide the unit onto the bracket and
align the motion detector for best coverage (see fig.).
c. Battery
Please replace the battery when the battery low indicator lights.
9. The Remote Control (order code HAM1000WS/RC, incl.)
a. Battery Installation
1. Open the battery cover using an appropriate screwdriver and install 1 x CR2032 battery (incl.). Mind the
polarity. The batteries should last 5 to 6 months (normal operation).
2. Close the battery compartment.
b. Transmission Range
The transmission range is ± 20m. Replace the batteries if you have to
shorten this range.
HAM1000WS_v3 6 VELLEMAN
