Querying statuses

Querying areas and triggering
statuses
Description
The status of ON/OFF areas (armed/dis-
armed) and their triggering of detectors can
be displayed on the display. For example, in
order to properly arm the system, all doors
and windows must be in normal condition
(closed). This function can be used, for ex-
ample, to locate corresponding detectors and
detector zones in the system. Example – dis-
play:
15 : 13 22.11.2005
MENU
Procedure
1. Start a query. Press the center
"menu" key.
The query display will appear.
ID:0 CO:
AREA PROG.
2. Call up areas. Press the left
The first area and its status will be dis-
played.
AREA 01 = OFF
NARM
3. Call up additional areas. Press the right
key.
The right key can be used to call up
additional areas consecutively. After the
last area, "AREA 01" reappears in the dis-
play. If the area is not ready for arming,
"NARM" (reasons for "not ready for arm-
ing") appears in the display.
AREA 02 = OFF
NARM
4. Call up an area's triggering. Press the cen-
ter
The reasons for "not ready for arming" will
be displayed.
0005 - 13 = TRIGGE
5. Call up an area's additional triggering.
Press the right
The right
the area's additional triggering consecu-
tively. After the last triggering, the first trig-
gering reappears in the display.
0005 - 17 = TRIGGE
6. Call up additional information. Press the
center
Additional information for the triggering will
be displayed for approximately 3 seconds.
0005 - 13 = TRIGGE
Window room 6
key.
7. Return. Press the "STOP" key twice.
The "STOP" key causes a return by one
level. The query will be ended.
ID:0
AREA
- 7 -
key.
?
key.
key can be used to call up
?
key.
CO:
PROG.
