Side brush cleaning

Side brush replacement
Please replace the side brush when it is desroyed.
Please remove the screws, and
take out the side brush.
Driving wheel cleaning

Up-ground height sensor cleaning

Side brush is a kind of easy wear part. We suggest you to check it
every time it takes cleaning task. Please change it if necessary.
Note
The host will alarm when the side brush tangled and the lights
Please push the new side brush
into the correct position.
Please use the roll brush cleaning gadget to remove the dust or
hair on driving wheel.
Note
If the wheel is tangled by hair or cloth, the host will alarm
and indicator will light
Up-ground height sensor is on the front bottom of robot. It can
detect the height difference over 8 centimeters. We suggest you
to wipe the optical board with dry cotton cloth after it finishes task
to prevent the dust piling on it which would affect its performance.
1. Turn off the power and remove the trash inside dust box.
2. Invert the robot, then put it on the even and clean platform.
3. Use dry cotton cloth to wipe three pieces of optical board of
up-ground height sensor.
Tide the screws.
.
