5. Overview
Refer to the illustrations on page 2 of this manual.
1 Camera Lens
2 LED Light
3 Microphone
4 Power button + LED
5 Live Record
6 Snapshot
7 LED Button
8 LED Flash
9 Open
10 Wrist Strap Hook
11 Mount Base
12 Battery compartment Holds 2 rechargeable lithium batteries.
13 USB Port
14 Micro SD Slot
6. Use
Refer to the illustrations on pages 2 and 3 of this manual.
Charging
• Open the housing. To do this, press the open button [9] and gently slide the
housing open towards the back. Insert batteries (refer to §8)
• Connect the USB-port [13] to a PC using the included cable. The LED [4] turns
red. The batteries are now being charged. Charging via PC might take from 8 to
12 hours; via an adaptor charging will take ±4h. Make sure batteries are
sufficiently charged before use.
Setting date/time
• Open the housing.
• Insert a micro SD card (not incl.) into the card slot [14]. Refer to the indication
next to the slot for the right direction. Only use a new card from a reliable
brand. Approximate recording times:
HD 1280x720 (30FPS)
Recording Time (Hours)
Note: preferably use an empty formatted card to avoid recording problems.
• Press the power button [4] shortly. After ±10s a blue LED under the power
button starts flashing. Press the live record button [5] to put the camera in
standby mode.
• Connect the USB-port [13] to a PC using the included cable. The LED turns red
and the camera now acts as a removable hard disk.
• To set date and time, locate the program 720Ptime.exe on the included
23.11.2010
CAMCOLVC13
Clean the lens by soft dry cloth before usage
2 Powerful LED to light/flash during low light
situations.
Advanced sensitivity microphone to record audio
Press to turn on/off the camera
Press to record live videos or stop recording.
Press to take single JPG photos
Press to turn on/ off LED light
Press to flash LED light or stop flashing LED
Push to open the casing
Attach wrist strap (included)
To support brackets and straps
Plug in USB cable to upload data
Insert Micro SD card (up to 32 GB supported)
2GB 4GB
1
5
8GB
2 4
Rev. 01
16GB 32GB
8 16
