specifications plate.
3. Always keep your hands away from the cutting area.
Always grip the machine safely.
4. Use protective goggles.
5. Always use original VIRUTEX tools. Never use defective
or damaged tools.
6. Always use cutter bits with the appropriate stem diameter
for the chuck collet and tool speed to be used.
Unplug the machine from the power su-
pply before performing any maintenance
operations.
2. SPECIFICATIONS
Input power...........................................................................750 W
Universal motor.........................................................50/60 Hz
No-load speed...................................................14,000 – 30,000/min
Ø max bit..........................................................................25 mm
Ø standard chuck collet.......................................................6 & 8 mm
Weight....................................................................................2.2 Kg
Weighted equivalent continuous
acoustic pressure level A.........................................................83 dBA
Acoustic power level A.............................................................94 dBA
Uncertainty......................................................................K = 3 dbA
Wear ear protection!
Vibration total values.................................................a
Uncertainty....................................................................K: 1.5 m/s
3. STANDARD EQUIPMENT
Inside the carrying case the following items will be
found:
• FR292R Router with 8 mm collet (*)
• Straight cutter for trimming and slotting D.18 LC. 20
• Key: 11 mm for motor shaft.
• Key: 19 mm for chuck collet attachment.
• Copying device
• Lateral square with centring shaft
• 3-mm Allen wrench
• Operating instructions and other documents
(*) (Machines at 120 V are equipped with 6.35 mm (1/4")
collet.)
4. GENERAL DESCRIPTION OF THE ROUTER
The FR292R router can be used for trimming laminates,
shaping small mouldings, rabbeting, making straight cut-
outs, chamfering, etc. Its head may be tilted from 0 to 91.5°
to cut bevelled edges and chamfer using cylindrical cutters
plus many more applications.
It micrometric copying wheel also allows interior curves
with radii over 52 mm to be cut.
It can also cut copies from templates using the copiers or the
template guides shown in section 11 and it can cut or shape
circles using the lateral square and centring shaft.
10
5. ASSEMBLY OF THE ROUTER AND ITS ACCESSORIES
5.1 ASSEMBLING AND CHANGING THE CUTTER
To change or assemble a cutter in the machine (Fig. 1), block
the motor shaft using the key U, unscrew the nut using
the service key Z, take out the used cutter and attach the
new one placing it into the bottom of its housing and then
tighten using the service keys.
5.2 ASSEMBLING THE COPYING DEVICE
Place copying device set M (Fig. 2), through holes O (Fig.
3) on the head and fix it at the required height using
screws H (Fig. 2).
: 3.1 m/s
2
h
2
5.3 ASSEMBLING THE LATERAL SQUARE
Place lateral square W (Fig. 5), through holes C (Fig. 4) on
the head and fix it at the required height using screws H.
5.4 ASSEMBLING THE CENTERING DEVICE
Attach the central shaft in the position indicated in Fig. 6,
together with the spacer and the stop washer, and fix them
with the nut supplied.
6. ADJUSTMENTS
6.1 ADJUSTING HEAD TILT
With the FR292R router, head tilt may be set for the cutter
head to be between 0 and 91.5° and may be locked in any
position using screws N (Fig. 7 y 8).
To trim with the 90° conical bit, place the head at 45° +1°
= 46° approximately, to avoid damaging the coating of the
Disconnect the machine from the power
supply before assembly.
Check that the stem diameter of the chuck collet
matches that of the cutter stem to be used.
Disconnect the machine from the power
supply before assembly.
Disconnect the machine from the power
supply before assembly.
Disconnect the machine from the power
supply before adjustment.
