Mounting installation kit

Attention: The correct installation of the installation kit is a prerequisite for the proper functioning
of the NEPTUN jet stream. For further information, please contact your pool specialist supplier or
visit www.neptun-int.com to ask for more data or further information.
The correct installation height of the installation kit is indicated in fig. 1 The earthing screw (see
fig. 2) must be located on the outside of the pool (shaft) and must point to the upper side (water
surface). The two major opening (inflow and extraction) must be mounted necessarily perpendi-
cular (at a right angle to the base plate). That`s the only way a correct mounting of the inlet aper-
ture and the pumping set is possible. Make sure not to soil the mounting parts and the threads
for the later flange or pump angle assembly during concrete work (use building protection). When
laying the film mount the flat gasket on the built-in pot, then fix the film and flange with 4 screws
(bill 4). Note fig.1: Only use the with X marked threads.
Threads marked with this symbol are used to take up the 4 distance screws
(list of parts 5) which are required for the mounting of the inlet aperture.
Mounting the base unit:
1.Start with the installation of the implementations for the on-off button and the air connection
(fig. 1). The air connection (list of parts 2) is to be mounted with the hose to the outside, so that
the air supply hose (list of parts 11) can be later attached to the inlet aperture (list of parts 13) in
the inside. Concerning the implementations make sure that the seal is on the outside of the pool.
The threaded parts of the bushings must be put through from the outside of the pool to the in-
side and secured with the matching nuts. Note fig. 3
2. Then mount the two pump angles (bill 3) with the 4 screws and washers (list of parts 4). Note fi-
gure 4
3. Prepare the pump unit and mount the 4 bearing blocks ( list of parts 5) with 4 nuts and washers
(list of parts 7). Mount the flat gasket (list of parts 6) at the front oft he pump unit and slide the
pump on the angles through the provided openings. fig 5
4. Put the pump flange (list of parts 8) from the inside of the pool to the protruding screws or
clips, and fix it with 6 nuts and washers (list of parts 7).
5. „Overdraft" the 45 cm air hose with the spring (list of parts 9) (antikink) and attach it at the im-
plementation of the on-off switch at the installation kit. Then push the clamping collet (short/wide)
over the hose and fix the hose with the clamping collet. Mount the air supply hose (list of parts
11) at the provided implementation of the installation kit. fig. 6
6. Then bolt the pump with the pump angle with the help of the screws and
washers ( list of parts 12).
7. Connect the implementation of the on-off switch with the help of the pneumatic hose 2.5 m (list
