INSTALLATION AND INSTRUCTION MANUAL
EN
NARVI ULTRA SMALL 6kW
NARVI ULTRA
NARVI ULTRA BIG
Please read the manual carefully before you start installing and using it and keep the
manual for future reference. The products are meant only to be used as a sauna heater
and for heating the sauna.
TECHNICAL DATA
ULTRA SMALL
ULTRA
ULTRA BIG
1. ONE ELECTRIC SAUNA STOVE PACKAGE COMPRISES:
1. Stove
2. Fixing screws
3. Installation and instruction manual
The sauna controller is not included in the heaters price. The external controller that is connected
with the heater must be designed for sauna control purpose.
2. PRIOR TO INSTALLATION:
Perform the following checks:
- The stove is the right size (kW) for the size of the sauna (m
- Table 1 shows the sauna volumes for different stove types.
- For every 1 m of uninsulated brick, tile or glass wall surface in the sauna, increase
2
the sauna volume by 1.5 m
The sauna volumes indicated in Table 1 are both maximum and minimum values.
- Table 1 indicates both the minimum height of the sauna and the minimum safety
distances for the stove.
ONLY ONE ELECTRIC STOVE TO BE INSTALLED IN A SAUNA.
This appliance is not intended for the use of children or other people, whose physical, sensory or
mental abilities, or the lack of experience or knowledge prevent them from using the appliance in
a safe manner, unless a person responsible for their safety is monitoring them and has instructed
them on how to use the appliance.
ALWAYS CHECK THE SAUNA BEFORE SWITCHING ON THE STOVE.
9kW
9kW 10,5kW 12kW
18kW 21kW 24kW
Width Depth
mm mm
440 300
440 420
860 420
when choosing the required stove wattage from Table 1.
3
15kW
27kW
Height Weight
, kg
mm
without stones
(
680 15
680 20
680 50
).
3
30kW 33kW
)
