1 In systems designed to accommodate this signal, during a call from an entry panel, the LED lit permanently indicates
that the door is open.
2 The function may also be available with communication is not activated, where the system permits it.

Standard functions

Answering a call
EN
Functions available during a call
Activation of communication
controls .
2
THESE INSTRUCTIONS SHOULD BE ATTACHED TO THE UNIT
1
2
, opening of the door of the selected entry panel
Adjusting the ring (high-medium-off ) (red LED)
Activating/deactivating communication (blue LED)
Door lock release (blue LED)
1
Intercom 1/3 (blue LED)
Intercom 2/4 (blue LED)
Auxiliary 1 (blue LED)
Auxiliary 2/Porter call (blue LED)
Answering a call
Communication active
Entry panel door release displayed
Ending communication
2
and activation of the auxiliary
