Measuring the thickness of the floor of an object
(see fig. E):
j
First measure the depth of the object.
j
Leave the depth blade
to obtain the zero position (ZERO)
j
Now measure the entire object.
The LCD display
the object.
Measuring the distance between two identical
holes (see fig. F):
j
First measure one of the two, equally sized holes.
j
Leave the measuring jaws
the key to obtain the zero position (ZERO)
j
Now measure the total dimension.
The LCD display
Characteristics of metric ISO screw threads:
Nominal diameter:
[mm]
3
4
5
6
8
10
12
16
20

Troubleshooting

Q
The device contains sensitive electronic components. That is why
it experiences interference when in close proximity to radio trans-
mission devices. If any indication errors appear in the display,
remove such devices out of the proximity of the calliper.
Electrostatic discharge could result in malfunctions.
j
When such malfunctions occur, remove the battery for a
short while and re-insert.
Failure
Five digits flash
simultaneously
every second.
The LCD dis-
play
not continue to
count.
10 GB
033_PL-HU-CZ-SK_Content.indd 10
5
5
Increase:
[mm
0.5
0.7
0.8
1
1.25
1.5
1.75
2
2.5
Cause
The battery voltage is
lower than 2.75 V.
Faulty wiring or
does circuit
5
in this position and press the key
6
9
now shows the thickness of the floor of
/ in this position and press
2 11
now shows the average distance.
Core diameter:
] [mm]
-1
2.46
3.24
4.13
4.92
6.65
8.38
10.11
13.84
17.29
.
.
9
Drill
diameter:
[mm]
2.5
3.3
4.2
5
6.8
8.5
10.2
14
17.5
Solution
Replace the battery
in line with the chap-
ter on "Inserting /
replacing battery".
Remove battery
and re-insert after
30 seconds.
