Britax KIDFIX XP SICT Gebrauchsanleitung Seite 4

PAGE II
7. SAFETY NOTES
Please take the time to read these instructions carefully and keep
them to hand in the intended storage compartment on the child
13
safety seat at all times! The instructions must be with the child safety
seat if the latter is passed on to a third party.
DANGER! For the protection of your child:
• In the event of an accident with a collision speed of more than 10 km/h, the
child safety seat may be damaged without the damage becoming imme-
diately visible. In this case the child safety seat must be replaced. Please
dispose of it properly.
• Have your child safety seat checked as a rule if it was damaged (e.g if it
falls to the ground).
• Regularly check all important parts for damage. Ensure that all mechanical
parts, in particular, are fully functional.
• Never lubricate or oil parts of the child seat.
• Never leave your child unattended in the child seat in the vehicle.
• Let your child in and out of the vehicle from the pavement side as a rule.
• Protect the child safety seat against intensive direct sun radiation,
as long as it is not in use. The child safety seat can become very hot
under direct sun radiation. Child skin is sensitive and could thereby
be injured.
• The more snugly the harness fits over your child's body, the better your will be
protected. Therefore avoid putting thick clothes on your child under the belt.
• Take regular breaks on long journeys in order to give your child the opportu-
nity to play around.
• Use on the rear seat: Push the front seat forwards sufficiently so that the
feet of your child do cannot hit the backrest of the front seat (to avoid the
risk of injury).
DANGER! For the protection of all vehicle occupants:
In the case of an emergency stop or an accident, unsecured persons or
objects may cause injury to other vehicle occupants. Please always check
that...
• the backrests of the vehicle seats are locked (i.e. that a foldable rear seat
bench latch is engaged).
• all heavy or sharp-edged objects in the vehicle (e.g. on the parcel shelf) are
secured.
• all persons in the vehicle have their seatbelts fastened.
• the child safety seat is always secured when it is in the vehicle, even if no
child is being transported.
WARNING! For your protection when handling the child seat:
• Never use the child safety seat free-standing, not even for test sitting.
• When swivelling up the backrest 14 , nothing must come between the back-
rest 14 and the seat cushion 10 . You or your child could pinch your fingers,
injuring them.
• To avoid damage, ensure that the child safety seat is not jammed in between
hard objects (car door, seat rails, etc.).
• Keep the child safety seat in a safe place if it is not in use. Do not place any
heavy objects on the seat and do not store it directly next to sources of heat or
in direct sunlight.
CAUTION! To protect your vehicle:
• Certain car seat covers made from more sensitive materials (e.g. velour, leath-
er, etc.) may sustain signs of wear and tear when using child safety seats. For the
optimum protection of your car seat covers, we recommend using the BRITAX
RÖMER child safety seat surface from our accessories programme.
8. ADJUSTING THE HEADREST
A correctly set headrest 22 ensures that the diagonal seat belt section
optimally positioned, and gives your child optimum protection.
The headrest 22 must be adjusted so that there is a space two fingers wide
between the headrest and your child's shoulders.
22
To adjust the height of the headrest to fit your child:
1. Reach into the adjustment handle 12 on the back of
12 22
the headrest and pull it towards you.
22
This unlocks the headrest.
2. You can now move the unlocked headrest
the desired height. As soon as you release the
adjustment handle , the headrest
12 22
into place.
3. Place the child safety seat on the vehicle seat.
22
4. Have your child sit down in the child safety seat and
check the height. Repeat the procedure until the
headrest has the correct height.
03
9. INSTALLATION
A
With ISOFIT + 3-point belt
The KIDFIX XP SICT is installed permanently in the vehicle with the ISOFIT
locking arms.
Your child is then buckled into the child seat with the vehicle's 3-point seatbelt.
01
1. If your vehicle is not fitted with ISOFIX insert guides by standard, clamp
the two insert guides 02 , with are included in the scope of delivery of
the seat*, with the section pointing upwards to the two ISOFIX fastening
points 01 of your vehicle.
TIP! The ISOFIX fastening points are located between the surface and the back-
rest of the vehicle seat.
* The insert guides facilitate the installation of the child safety seat with the use of the
SOFIX fastening points and prevent damage to the car seat covers. As long as they
are not used, remove them and keep them in a safe place. For vehicles with foldable
a backrest, the insert guides need to be removed before folding the backrest. Any
problems occurring usually come from soiling or external objects on the insert guides
and on the hook. Remove soiling or external objects to rectify such problems.
2. Moving the headrest of the vehicle seat into the top position.
3. Carry out the steps in Section 8 „ADJUSTING THE HEADREST".
4. Hold the ISOFIT settings button down and push the ISOFIT locking
09
.
arms 06 out in full
5. Push the green safety button
release button on both sides of the seat towards
07
09
each other. This ensures that both hooks on the
ISOFIT locking arms
06
06
6. Place the XP-PAD on the side of the child safety
11
07 08
seat closer to the vehicle door.
7. Guide the elastic holding strap of the XP-PAD
into the dark red belt holder
11
14
until it lies completely in the belt holder
03
not twisted.
11
8. Place the child safety seat in driving direction
on a vehicle seat approved for use.Ensure that
the backrest 14 is flush with the backrest of the
vehicle seat .
9. Position the two ISOFIT locking arms
front of the two insert guides
16 is
02 06
10. Push both ISOFIT locking arms
guides until the ISOFIT locking arms
02
gage on both sides with a clicking sound.
DANGER! The green safety button
visible on both sides so that the child
to
22
safety seat is correctly fastened.
will lock
11. Hold the ISOFIT settings button
the child safety seat as far back as possible.
09
08
12. Shake the child safety seat to ensure that it is
securely fastened and check again the fastening
buttons
13. Carry out the steps in Section 10 „SECURING
YOUR CHILD".
For the safety of your child, before every journey in the car check
that...
►the child safety seat is slotted in on both sides with the ISOFIT locking
02 arms 06 in the ISOFIT fastening points
fully green;
►• the child safety seat is securely fastened;
15
►the lap belt runs in the bright red belt guides on both sides of the seat
cushion 05 ,
►the diagonal seat belt section
18 also runs through the light red belt guide
►the diagonal seat belt section
of the headrest,
►XP-PAD 11 and XP-SICT 04
►the diagonal seat belt section
►the straps are tight and not twisted,
►The seatbelt buckle 18 must not be positioned on the red belt guide
the seat cushion.
DANGER! If your child tries to open the SOFIT safety buttons
hicle belt buckle 18 , stop immediately as soon as possible. Check whether
the child safety seat is correctly fastened and ensure that your child is cor-
rectly secured. Explain to your child the dangers associated with his actions.
UNFASTENING YOUR CHILD AND REMOVAL:
To unfasten your child or to remove the child safety seat, observe the
steps in Section 6 „REMOVAL" [PAGE I]
08 and the red
B
With 3-point belt
are open and ready to use.
The KIDFIX XP SICT is not installed permanently in the vehicle. It is simply
secured together with your child using the vehicle's 3-point seatbelt.
1. Carry out the steps in Section 8 „ADJUSTING THE
HEADREST".
2. Place the XP-PAD
seat closer to the vehicle door.
11
3. Guide the elastic holding strap of the XP-PAD
11 into the dark red belt holder
14
03 of the headrest 22 until it lies completely in the belt holder
not twisted.
4. Place the child seat on the vehicle seat. Ensure that
the backrest
03
vehicle seat.
11
Tip! If the headrest of the vehicle seat gets in the
way, turn it the other way.
03 and is 5. Carry out the steps in Section 10 „SECURING
YOUR CHILD".
For the safety of your child, before every journey in the car check
that...
►• the child safety seat is securely fastened;
15
06 directly in ►the lap belt runs in the bright red belt guides on both sides of the seat
02 . cushion ,
05
►the diagonal seat belt section
le also runs through the light red belt guide
18
►the diagonal seat belt section
of the headrest,
06 into the insert
►the diagonal seat belt section
en-
06
►the straps are tight and not twisted,
►XP-PAD and XP-SICT are correctly installed and used,
08 must be
►the seatbelt buckle 18 must not be positioned on the red belt guide
the seat cushion.
DANGER! If your child tries to open the vehicle belt buckle
immediately as soon as possible. Check whether the child safety seat is
correctly fastened and ensure that your child is correctly secured. Explain
09 down and push
to your child the dangers associated with his actions.
UNFASTENING YOUR CHILD AND REMOVAL:
To unfasten your child or to remove the child safety seat, observe the
steps in Section 6 „REMOVAL" [PAGE I]
10. SECURING YOUR CHILD
to ensure that both are fully green.
08
04
01 and both safety buttons 08 are
11
on the side of the vehicle seatbelt buckle
16
05 of the seat cushion,
16 runs through the dark red belt holder 03
are correctly installed and used,
runs diagonally backward,
16
18
05 in
08 or the ve-
16
15
05
15
16 22
on the side of the child safety
11
11 03
03 of the headrest 03
03 and is
is flush with the backrest of the 16
14
03
16
11
on the side of the vehicle seatbelt buck-
16
05 of the seat cushion,
16 runs through the dark red belt holder 03
16
16 runs diagonally backward,
05 in
18 , stop
16
1. Unscrew the XP-SICT anti-clockwise (on the side
04
closer to the vehicle door) until it has a distance of
5 mm to the vehicle door or has been unscrewed to
the maximum.
2. Let your child sit in the child safety seat and place
the XP-PAD 11 over the chest area of your child
3. Pull out the vehicle belt and guide it in front of your
child to the vehicle seat buckle .
18
DANGER! Ensure the vehicle belt is not twisted, as
otherwise the full protective effect of the
retaining system is not ensured.
4. Engage the buckle tongue in the vehicle seat buckle
18 with a CLICK!
5. Place the diagonal seat belt section 16 and lap
belt section on the side of the vehicle seatbelt
15
buckle 18 into the light red belt guide 05 of the seat
cushion.
05
DANGER! The vehicle seatbelt buckle 18 must
not be positioned between the light red
18
belt guide 05 and the armrest.
6. Also place the lap belt section
15 on the other side
of the seat cushion in the light red belt guide 05 .
DANGER! The lap belt section must lie as low
15
as possible over your child's hips on
both sides.
7. Guide the diagonal seat belt section 16 into the dark
red belt holder of the headrest until it lies
03 22
completely in the belt holder 03 and is not twisted.
14
Tip! If the backrest conceals the belt holder 03 ,
you can adjust the headrest upwards. The diagonal
22
seat belt section can now be easily inserted. Now
16
return the headrest 22 to the proper height.
8. Ensure that the diagonal belt 16 runs over the
collarbone of your child and is not on the neck and
that the key on the belt holder is 03 fully closed.
Tip! You can still adjust the height of the headrest
again here in the vehicle.
22
9. Open the Velcro fastener on the XP-PAD 11 and
fold the top part of the XP-PAD to the side.
11
10. Insert the diagonal belt 16 in the die nubby surface
of the XP-PAD 11 .
11. Close the XP-PAD again by folding the folded
11
part back and closing the Velcro fastener.
DANGER! The diagonal seat belt section must
16
run diagonally backward. You can
adjust the course of the belt with your
vehicle's adjustable belt deflector.
DANGER! The diagonal belt 16 must never be
directed forwards to the belt deflector on
the vehicle. In this case, use the child
safety seat on the back seat only.
12. Tighten the vehicle seat belt by pulling on the diag-
onal seat belt section .
16
13. Observe the further steps of the relevant installa-
tion type.
