CV - Table
Standard settings of the 8FS-decoder. (D = Default, A = analog operation)
Table of configuration variables (CV table)
CV Description
1
Loco address (standard short)
2
Starting voltage
3
Acceleration time
4
Braking time
5
Top speed
6
Mid speed
5+6 Register mode programming
Reg 6 = CV Number
Reg 5 = CV Value
7
Software version
8
Manufacturer ID
8
Decoder reset functions (refer to Attachment 5)
(5 ranges available)
11 Analog Time Out
Function outputs in analog mode
13
(On if value set)
15 Programming lock
16 Programming lock
17 Long loco address (High Byte)
18 Long loco address (Low Byte)
D
A
Range
Note
3
1...127 if CV 29 bit 5 = 0
2
1...255 CV 2 x (1/255 track voltage)
3
√
1...255 CV 3 x 2ms x (1/255 track v.)
3
√
1...255 CV 4 x 2ms x (1/255 track v.)
200 √
1...255 CV 5 x (1/255 track voltage)
50
1...255 CV 6 x (1/255 track voltage)
CV 5 and CV 6 are not effected
---
---
read only
123
---
read only
11
basic settings
16
Programming lock
22
LF/LR and FA1...FA2
33
FA3...FA6
44
FA7...FA8
66
Motor settings
222
Retailer lock
30 √
30...255 1ms per value
Add the values to the desired
functions!
0
√
0... 255
A1 = 1, A2 = 2, A3 = 4,
A4 = 8, A5 = 16, A6 = 32,
A7 = 64, A8 = 128
133
0...255
133
0...255 Default value for XL II Decoder
128...
Only active
128
10239
if CV 29 bit 5 = 1
21
