Start Surveillance - Dorr snapshot Extra Gebrauchsanweisung

insTaLLaTiOn Of ThE caMEra
Fix camera to a tree, pole or any suitable object. Best range is 3-10 meters from camera to object. For security reasons you
may obtain cable lock optionally.
DirEcTinG ThE caMEra
1) Hang up camera in about 0,75 - 1 m height, slightly tilting ahead
2) switch camera to "setup" and close housing.
3) move in front of camera. When red light is flashing you see the area which is covered by the PIr sensor
4) It is recommended to test the position and take several test photos, to see the area covered by the camera
5) switch the camera off now

sTarT surVEiLLancE

to make the camera ready:
1. switch camera to „setup". camera logs into the mobile network. If login was successful display shows provider and
signal strength.
2. switch camera to „on" and close housing. after 15-30 seconds camera is ready.
caMEra chEcK uP
options to check if the camera has taken pictures:
1) open camera housing and enter setup mode
2) the lower line of starting menu shows the number of pictures taken and the remaining full space
3) Press to view the pictures
4) alternatively switch camera off and exchange the memory card with a fresh one. so you can view images on your computer
or tV.
It is recommended to check the battery status as well. When capacity goes down, it will be more difficult to achieve correctly
illuminated night shots. In case of doubt, replace batteries with new ones.
TiPs & TricKs
1. siM carDs
unlock your sIm card, there is no possibility to enter the sIm password. Before the sIm card is used, you need to register the
card by dialing a number first.
warning: no support for micro sIm cards!
the camera transmits images via mms or email. Please make sure that these services are unlocked and that they are sup-
ported by your provider. the transmitter modules in the camera support the following bandwidth: 850mHz, 900mHz, 1800mHz
and 1900mHz.
2. MObiLE nETwOrK
the signal strength of the mobile network can be very different, which may cause interference in image transmission. Please
check carefully whether the signal strength is sufficient (ideally full strength on display) and that the antenna is mounted
correctly.
3. sMs cOMManDs
If camera does not react to sms commands, activate function by sending sms command #200#on# with the operator phone
number.
4. sD MEMOry carDs
the camera operates only with a sd memory card. some sd cards do not harmonize with the dÖrr snapshot and restrict
22
