* For more information on the riser board slots supported by the onboard PCI riser connectors, see "PCIe
riser board slot definitions (on page 9)."
DIMM slot locations
DIMM slots are numbered sequentially (1 through 6) for each processor. The supported AMP modes use
the letter assignments for population guidelines.
Description
Fan connector 8
Fan connector 7
Fan connector 6
Fan connector 5
Fan connector 4
Internal USB connector
Fan connector 3
Fan connector 2
Fan connector 1
Processor 2 DIMM slots
Reserved
Drive backplane power connector
Processor socket 2
Reserved
Power supply connector 1
Drive sideband signal connector
Power supply connector 2
Processor 1 DIMM slots
SD card slot
NMI header
System maintenance switch
Component identification 10
