Action
Access Help for a highlighted configuration
option*
*Scan the QR code on the screen to access online help for the UEFI System Utilities and UEFI Shell.
Default configuration settings are applied to the server at one of the following times:
•
Upon the first system power-up
•
After defaults have been restored
Default configuration settings are sufficient for typical server operations; however, you can modify
configuration settings as needed. The system prompts you for access to the System Utilities each time the
system is powered up.

Configuration procedures

Legacy mode boot options

Setting a controller as the boot controller
For servers running in legacy (non-UEFI) mode, use the following procedure to set a controller as the boot
controller using HPE SSA. To adjust the boot order settings for other controllers in the system, see
"Setting the controller order (on page 18)."
Confirm that the controller is connected to a logical drive. (If it is not, it cannot be set as the boot
1.
controller.)
Perform a normal system shutdown.
2.
Restart the server.
3.
POST runs, and the system recognizes devices. When the system recognizes the controller you
want to set as the boot controller, continue with the next step.
Press the F5 key.
4.
After POST completes, the system launches the HPE SSA GUI, or if you are using Serial Console,
the system launches the HPE SSA CLI.
Select the appropriate menu option, and follow any subsequent on-screen instructions. If prompted
5.
to save the settings, do so.
(Optional) To configure or reconfigure an array on this controller, you can use HPE SSA. For more
6.
information, see the HPE Smart Storage Administrator User Guide.
To configure an array at a later time or to use a different utility to configure the array, exit HPE SSA,
and then restart the server for the new boot controller setting to take effect.
Setting the controller order
For servers running in legacy (non-UEFI) mode, use the following procedure to set the controller order
using RBSU.
Power up the server.
1.
The server runs the POST sequence and briefly displays an RBSU prompt.
At the prompt, press the F9 key. After POST completes, RBSU starts.
2.
Follow the on-screen instructions to set the boot order for the different controllers in the system.
3.
Save the settings.
4.
Exit from the utility.
5.
Key
F1
Installation and configuration 18
