of Standards and Technology website
(http://csrc.nist.gov/groups/STM/cmvp/documents/fips140-2/FIPS1402IG.pdf).
For more information about Smart Array P830 Controller, see the Secure Encryption Installation and User
Guide on the Hewlett Packard Enterprise website (http://www.hpe.com/info/smartstorage/docs).

Supported servers

For more information on installing the controller in a supported server, see the server user guide.
For the latest support information, see the controller QuickSpecs on the Hewlett Packard Enterprise
website (http://www.hpe.com/info/qs).

Controller specifications

Feature
Controller
Board type
Dimensions, cm*
Dimensions, in*
I/O connection to
the system board
Maximum power
required
(approximate)
Internal SAS
connector life
expectancy
Cache module
and battery or
capacitor pack**
Cache module
Time required to
recharge battery
or capacitor pack
Duration of battery
or capacitor pack
backup
Battery or
capacitor pack life
expectancy
Drives
Supported drive
types†
Description
Low-profile, PCIe stand-up board
16.8 x 6.9 x 1.7
6.6 x 2.7 x 0.6
PCIe3 x8 edge connector
14.5 W
250 connect/disconnect cycles
2 or 4 GiB FBWC
Approximately 200 MB from the cache module is
required to run the controller firmware. The remainder of
the available space can be configured for read-ahead or
write back caching.
5 minutes or less
80 seconds
The battery or capacitor pack provides a sufficient
duration to transfer the cached data from DDR memory
to flash memory, where the data remains indefinitely or
until a controller retrieves the data.
More than 3 years
•
6 Gb/s SAS
•
6 Gb/s SATA
•
12 Gb/s SAS
Not all servers or storage systems support all SAS or
SATA drive types. For product-specific drive support,
see the product QuickSpecs on the Hewlett Packard
Enterprise website (http://www.hpe.com/info/qs).
