Parts List – Spare Parts List
AL 4 Order No. 1611(A)
Technical data:
Issue: 01. 03. 2017
Ergometer of Class HA with high accuracy
Combination of hometrainer and nordic walking.
Exercise your endurance and legs as well your arms
in a comfortable upright position.
• 32 –stepped Motor- and Computer-controlled magnetic resistance (Magne-
tic-Brake-System)
• Approx. 8 kg flywheel mass
• 12 stored training programs
• 4 heart rate programs with default of the maximum pulse rate (pulse guided)
• 4 individual programs
• 1 manual program
• 1 speed independent program (Default of wattage from 10 – 350 watt steps,
resistance adjustable in 5-watt steps)
• Hand pulse measurement
• Horizontally and vertically adjustable comfort saddle
• Floor level compensation
• Transport rollers
• Power plug (Adapter)
• Back light LCD display, 7 window display with simultaneous display of:
Time, Speed, Distance,
approx. Calorie consumption, RPM, Watt and Pulse frequency
• Input of individual limits: Time, Distance, approx. Calorie consumption, Pulse
frequency and Watt
• Announcement when limits are exceeded
• Body fat analysis (BMI)
• Load max. 150 kg (body weight)
Space requirement approx.: L 101 x W 64 x H 137 cm
Illustration
D
e
signation
No.
1
Computer
2
Screw
3
Cable plug
4
Nylon bushing
5
Wavewasher
6L
Hand grip left
6R
Hand grip right
7
Screw
8
End cap
9
Hand wrapping
10
Hand pulse sensor
11
Pulse cable
12
Pulse connection cable
13
Allen bolt
14
Spring washer
15
Washer
16L
Connection tube left
16R
Connection tube right
17
Self-tapping screw
18L-1
Front plastic cover left
18L-2
Rear plastic cover left
18R-1
Front plastic cover right
18R-2
Rear plastic cover right
19
Connection cable
20
Seat
21
Square plug
22
Seat slide
23
Fixed bracket
24
Washer
25
Hand grip nut
26
Seat support
Items weight: 34kg
Exercise space approx: min. 2,5m²
Please check after opening the packing that all the parts shown in
the following parts lists are there. Once you are sure that this is the
case, you can start assembly.
Please contact us if any components are defective or missing, or if
you need any spare parts or replacements in future.
Internet service- and spare parts data base:
www.christopeit-service.de
Top-Sports Gilles GmbH
Friedrichstr. 55
42551 Velbert
Telefon: +49 (0) 20 51 - 6 06 70
Telefax: +49 (0) 20 51 - 6 06 74 4
e-mail: info@christopeit-sport.com
www.christopeit-sport.com
This product is created only for private Home sports activity
and not allowed to us in a commercial or professional area.
Home Sport use class H/A
0
5
10 15 20 25 30 35 40
imensions
Quantity
D
mm
1
M5x10
4
12
3
19x38
6
19//38.5
2
1
1
M4x25
4
2
2
2
2
2
M8x20
2
for M8
16
8//36
2
1
1
4.5x25
13
1
1
1
1
1
1
38x38
2
1
1
10//25
1
M10
1
1
17
50
60
70
80
90
Attached to
ET number
illustration No.
92
36-1611-03-BT
1+92
39-9903
6+92
36-9134-22-BT
16+92
36-9825328-BT
93
36-9925114-BT
16L
33-1610-05-WS
16R
33-1610-06-WS
10
36-9111-38-BT
6
36-1611-07-BT
6
36-1610-10-BT
6
36-1610-11-BT
6
36-1610-12-BT
1+11
36-1611-10-BT
93
39-9886-CR
13,56+99
39-9864-VC
13
39-10166
6L+31
33-1611-07-WS
6R+31
33-1611-08-WS
16+46
36-9825338-BT
16L+18L-2
36-1611-11-BT
16L+18L-1
36-1611-12-BT
16R+18L-2
36-1611-13-BT
16R+18R-1
36-1611-14-BT
1+94
36-1507-15-BT
22
36-9806210-BT
22
36-9211-23-BT
20+22
33-9211-07-WS
22
33-9211-08-SI
23
39-9989-CR
23
36-9211-19-BT
22+57
33-1611-09-WS
