10/16 DBD | Druckbegrenzungsventil
Abmessungen: Plattenaufbau
(Maßangaben in mm [inch])
Druckbegrenzungsventil
NG B1
6 45 [1.77]
10 60 [2.36]
20 70 [2.76]
30 100 [3.94]
NG L4
6 55 [2.17]
10 70 [2.76]
20 100 [3.94]
30 130 [5.12]
Anschlussplatten
NG Typ
6 G300/01 [G300/12]
10 G661//01
G662/01
20 G303/01
G304/01
30
G305/01
G306/01
NG ØD10 ØD11
6
6 [0.24] 8 [0.32]
10
10 [0.39] 8 [0.32]
10 [0.39] 8 [0.32]
20 15 [0.59] 8 [0.32]
20 [0.79] 8 [0.32]
30 30 [1.18] 8 [0.32]
NG L13
6
39 [1.54] 42 [1.65]
10
40,5 [1.59] 48,5 [1.91]
40,5 [1.59] 48,5 [1.91]
20 45 [1.77] 54 [2.13]
42 [1.65] 54 [2.13]
30 42 [1.65] 52,5 [2.07]
NG T6 R1
6 6 [0.24] 25 [0.98
+2
10
6 [0.24] 30 [1.18
+5
20
6 [0.24] 40 [1.57
+3
30
6 [0.24] 55 [2.16
+4
Bosch Rexroth AG, RD 25402, Ausgabe: 2014-08
B2 ØD3
60 [2.36] 6,6 [0.26]
80 [3.15] 9 [0.35]
100 [3.94] 9 [0.35]
130 [5.12] 11 [0.43]
L5 L6
40 [1.57] 20 [0.79]
45 [1.77] 21 [0.83]
65 [2.56] 34 [1.34]
85 [3.35] 35 [1.37]
B3 B4
45 [1.77] 60 [2.36]
60 [2.36] 80 [3.15]
60 [2.36] 80 [3.15]
70 [2.76] 100 [3.94]
70 [2.76] 100 [3.94]
100 [3.94] 130 [5.12]
100 [3.94] 130 [5.12]
H3
25 [0.98] 110 [4.33]
25 [0.98] 135 [5.32]
25 [0.98] 135 [5.32]
40 [1.57] 170 [6.69]
40 [1.57] 170 [6.69]
40 [1.57] 190 [7.48]
L14 L15
62 [2.44] 65 [2.56]
72,5 [2.85] 80,5 [3.17]
72,5 [2.85] 80,5 [3.17]
85 [3.35] 94 [3.70]
85 [3.35] 97 [3.82]
102,5 [4.04] 113 [4.45]
Masse, ca. in kg [lbs]
] 1,5 [3.3]
+0.079
] 2 [4.4]
+0.197
] 5,5 [12.1]
+0.118
] 8 [17.6]
+0.157
H2
40 [1.57]
60 [2.36]
70 [2.76]
90 [3.54]
L18 Anschluss (P)
15 [0.59]
15 [0.59]
15 [0.59]
15 [0.59]
ØD5 ØD6
6,6 [0.26] 11 [0.43]
6,6 [0.26] 11 [0.43]
6,6 [0.26] 11 [0.43]
11 [0.43] 18 [0.71]
11 [0.43] 18 [0.71]
11 [0.43] 18 [0.71]
11 [0.43] 18 [0.71]
L7 L8
8 [0.32] 94 [3.70]
10 [0.39] 115 [4.53]
10 [0.39] 115 [4.53]
15 [0.59] 140 [5.51]
15 [0.59] 140 [5.51]
12,5 [0.49] 165 [6.50]
L16 L17
15 [0.59] 1 [0.039]
15 [0.59] 1 [0.039]
15 [0.59] 1 [0.039]
15 [0.59] 1 [0.039]
15 [0.59] 1 [0.039]
15 [0.59] 1 [0.039]
Hinweis:
Die angegebenen Anschlussplatten sind zur Verwendung mit
baumustergeprüften Sicherheitsventilen nach Druckgeräte-Richtli-
nie 97/23/EG nicht zugelassen!
L1 L2
80 [3.15] 4 [0.16]
100 [3.94] 4 [0.16]
135 [5.32] 5,5 [0.22]
180 [7.09] 5,5 [0.22]
Masse, ca. in kg [lbs]
G1/4
G1/2
G3/4
G1 1/4 13,9 [30.6]
D7 ØD8
M6 [1/4-20 UNC] 25 [0.98]
M8 25 [0.98]
M8 34 [1.34]
M8 42 [1.65]
M8 47 [1.85]
M10 56 [2.20]
M10 65 [2.56]
L9 L10
22 [0.87] 55 [2.17]
27,5 [1.08] 70 [2.76]
27,5 [1.08] 70 [2.76]
20 [0.79] 100 [3.94]
20 [0.79] 100 [3.94]
17,5 [0.67] 130 [5.12]
T2 T3
15 [0.59] 9 [0.35]
15 [0.59] 9 [0.35]
16 [0.63] 9 [0.35]
20 [0.79] 13 [0.51]
20 [0.79] 13 [0.51]
24 [0.95] 11,5 [0.45]
L3
15 [0.59]
20 [0.79]
20 [0.79]
25 [0.98]
1,5 [3.3]
3,7 [8.2]
6,4 [14.1]
D9
G1/4 [SAE 4; 7/16-20]
G3/8
G1/2
G3/4
G1
G1 1/4
G1 1/2
L11 L12
10 [0.39]
12,5 [0.49]
12,5 [0.49]
20 [0.79]
20 [0.79]
22,5 [0.89]
T4 T5
15 [0.59]
12 [0.47]
15 [0.59]
22 [0.87]
22 [0.87]
22 [0.87]
