Figure 2: Example of multiple boards sharing same external supply. Refer to figure 2 for typical wiring. Make certain lip
on long power supply jumper engages retaining tab on T5 or T6 as shown in View A-A.
D500-67-00
PCB 1
+ —
EXTERNAL
POWER
SUPPLY
PCB 2
Figure 2
3
VIEW A-A
I56-2256-01
