Marker types
The RD8000 can detect 9 different RF Markers, as shown in the table below.
UTI L ITy
French Power
General / Non-drinkable water
Cable TV
Gas
Telephone/Telecoms
Sanitary
German Power
Water
Electrical Power*
*Use of the red Electrical Power (PWR) marker locate mode is subject to radio licensing restrictions
for Short Range Devices in the EU and possibly other countries. It is the responsibility of the user
to ensure that the red Power (PWR) marker locate mode is only enabled in countries where radio
licensing restrictions do not apply at the operating frequency of 169kHz.
If required and permitted use RD Manager to enable this frequency.

Using accessories

The locator and transmitter are compatible with a wide range of accessories. For detailed
information on using any of the accessories below please refer to the RD8000 locator
operation manual.
Signal clamps
When it is not possible to connect directly onto a pipe or cable, or induction mode is
unsuitable, a transmitter signal clamp may be used. The clamp is plugged into the output
of the transmitter and provides a means of applying a locate signal to an insulated live
wire. This is particularly useful with live insulated cables as it removes the need to disable
the power and break the line.
WARNING! Do not clamp around uninsulated live conductors.
WARNING! Before applying or removing the clamp around a power cable ensure
that the clamp is connected to the transmitter at all times.
To locate or identify individual lines a locator signal clamp can be connected to the
accessory socket of the locator and can be clamped around individual pipes or cables.
C OLOR D I S PLAy
AB B R EVIATI ON
Natural PFR
Purple PUR
Black/Orange CTV
Yellow GAS
Orange TEL
Green SAN
Blue/Red PDE
Blue H20
Red PWR
15
FR E qU E N Cy
40.0kHz
66.35kHz
77.0kHz
83.0kHz
101.4kHz
121.6kHz
134.0kHz
145.7kHz
169.8kHz
