Component
1
4
9 10
14
1
Heatsink Body ×1
4
Mounting Plate ×1
LGA2011 Type B
7
Screw Pillars x4
10
Intel Washer (small) ×8
13
Chill Factor III ×1
16
M3 L17 Screw ×5
The Ultimate Cooling Solutions!
2
5
11
15 16
2
Enhanced Fan Mount ×1
5
Anchoring Mount ×1
8
M3 L10 Screw ×5
11
AMD Washer (big) ×4
14
TY-14013R Fan×1
17
M3 L28 Screw ×5
3
6 7
12
17
3
Metal Back Plate ×1
6
Screw Nut ×4
9
M3 L6 Screw ×7
12
Back Plate Cap ×1
15 M3 L4
18
Mylar ×1
