RISK OF INJURY
Make sure that the blade guard
at at least the same angle as the additional
handle
(see fig. B). Otherwise, you could
injure yourself on the roughing disc or cutting
disc.
Turn the blade guard
(working position). Make sure that the blade
guard
is positioned in such a way that the
blade guard fixture
5 bulges
on the blade guard
(fold-out page).
Ensure that the blade guard fixture
seated in the respective bulge

Fitting the additional handle

CAUTION!
For safety reasons, this appliance may only
be used with the additional handle
ure to do so can lead to serious injury. The
additional handle
the left, the right or the top, depending on the
job at hand.
Fitting/changing the roughing/
cutting disc
Always wear protective gloves when changing
cutting/rough grinding discs.
Pay attention to the dimensions of the roughing/
cutting disc. The diameter of the hole must fit the
attachment flange
without any play. Do not use
a reducer or adapter.
NOTE
Use only discs which are free of dirt.
PWSA 20-Li B3
is fitted
to the required position
lies over one of the
(see Fig. E
is firmly
.
. Fail-
can be screwed onto
Use only grinding discs whose permissible
speed rating is at least as high as that on the
type plate on the power tool.
RISK OF INJURY! Press the spindle locking
button
only when the attachment spindle
is at a complete standstill.
Press the spindle locking button
motor.
Undo the clamping nut
mounting spanner
Place the rough grinding or cutting disc with the
label side towards the appliance on the attach-
ment flange
.
Then replace the clamping nut
ment spindle
with the raised side facing up.
With thin grinding discs (see fig. 1):
The collar of the clamping nut
so that a thin grinding disc can be fitted safely.
Fig. 1
Press the spindle locking button
motor.
Tighten the clamping nut
mounting spanner
With thick grinding discs (see fig. 2):
Fig. 2
The collar of the clamping nut
so that the grinding disk can be fitted securely onto
the attachment spindle
to lock the
using the two-hole
(see fig D).
on the attach-
faces upwards
≤ 3,2 mm
to lock the
using the two-hole
.
> 3,2 mm
faces downwards
.
