Taurus WS7 Handbuch Seite 15

Schritt 2: Explosionszeichnung
Nr. Bezeichnung (ENG)
7 weight stack rubber crash
8 hexagon sock button head
9 lock nut
10 weight stack lift bar
11 below steel weight stack
12 top steel weight stack
13 flexible opening latch
14 shim
86 magnetic pin
top steel weight stack(12)
partial enlarged drawing
Assembly step 2 explosion drawing
Bemerkung Anz.
Φ60*Φ26*20
M8*70
M8
92 KG
4,5 KG
9 KG
Φ10*80
Φ8
Φ10*100
small holes
2
2
2
1
18
1
1
4
1
15
