Product Description - Sharp LL-T15A4 Bedienungsanleitung

6 1 2
1. MENU button ............................ This button is used to pop-up, select and close the OSD (On Screen
2. / MODE button ..................... When the OSD Menu is displayed:
3. buttons ............................. When the OSD Menu is displayed:
4. Power button ............................ Pressing this button turns the power on. (After turning the power on, it
5. Power LED ............................... This LED is lit green when in use and orange when in power-saving
6. Speakers .................................. Audio entering via the external device connected to the monitor can be
7. Power terminal
8. Analog RGB input terminal ..... The analog signal cable is connected here. The analog signal cable
9. Audio input terminal ................ A computer
10. Security lock anchor ................ By connecting a security lock (commercially available) to the security
11. Headphone terminal ............... Headphones (commercially available) can be connected here.
12. Ventilation openings ................ Note: Never block the ventilation openings as this may lead to

Product description

3 4 5 6
Display) Menu.
This button is used to select menu options.
When the OSD Menu is not displayed:
This button is used to set DISPLAY MODE.
These buttons are used to select an option or adjust the value of the
selected option.
When the OSD Menu is not displayed:
These buttons are used to adjust backlight brightness and speaker
volume.
may take a little time before an image appears on the screen.)
Press the button again to turn the power off.
mode.
heard.
included should be used.
s audio output terminal can be connected here. The audio
'
cable included should be used.
lock anchor, the monitor is fixed so that it cannot be transported.
The security slot works in conjunction with Kensington Micro Saver
Security Systems.
overheating inside the monitor and result in malfunction.
7
9
12
8 9 10 11
