Controls and Connectors
14. 14. 13. 12.
1.
2.
3.
PRESETS
4.
5.
6.
ALARM INFO
7.
1. Power
2. Presets
3. Back
4. Mode
5. Alarm
6. Info
7. Down

Powering Uno

Your Uno radio is powered from the mains
using the power adaptor supplied.
Insert the power adaptor plug into the DC
power socket on the rear of Uno.
Pressing the button will switch Uno on.
Only use the power adaptor supplied.
Replacements are available, visit
www.revo.co.uk for further details.
24/9/08 10:30 Page 5
MODE
11.
10.
9.
SCAN SLEEP
8.
8. Scan
9. Sleep
10. Forward
11. Vol Up-Down
12. Mode
13. Up
14. Menu
4.
1.
1.
English
3.
2.
1. M-Port
2. Snooze
3. LCD Screen
4. Remote Control Sensor
2.
3.
1. Telescopic Antenna
2. 3.5mm Headphone Socket
3. DC Power Socket
