Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuseholder on the rear panel with a fitting screwdriver from the housing (anti-
clockwise).
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing and fix it.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only
in order to avoid hazards.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
DMX-control-channels:
DMX-512-connection:
Number of LEDs:
Beam angle:
Maximum PAN-movement 630°:
Maximum TILT-movement 265°:
Length of base:
Width of yoke:
Height (head horizontal):
Weight (net):
Maximum ambient temperature T
Maximum housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
Fuse:
Accessory:
FUTURELIGHT CP-240 controller
FUTURELIGHT CP-256/64 controller 16bit
FUTURELIGHT CP-512/64 controller 16bit
FUTURELIGHT CP-1024 controller 16bit
Wizard-512 USB DMX software + interface
Wizard-1024 USB DMX software + interface
FUTURELIGHT DES-3 DMX-terminator 3-pin
Please note: Every information is subject to change without prior notice. 17.03.2008 ©
230 V AC, 50 Hz ~
200 W
12
3-pin XLR
21
57°
in 2.5 s
in 1.5 s
420mm
370 mm
500 mm
19 kg
:
45° C
a
(steady state):
60° C
B
0.5 m
0.1 m
T 2 A, 250 V
No. 51834265
No. 51834288
No. 51834295
No. 51834310
No. 51860102
No. 51860110
No. 51834001
44/44
00035683.DOC, Version 1.0
