OPERATING INSTRUCTIONS

Insertion of the Flocare ® Infinity ™ pump set
• Connect the set to the feed container as instructed on the packaging
of the Flocare ® Infinity ™ pump set.
Remove the dust cap from the step connector.
• The Flocare ® Infinity ™ pump sets are equipped with an "automatic
free-flow protection", as a consequence the set has no roller clamp.
Fill the pump set completely with feed by gently pinching on the
side of the cassette that is marked with a drop (point A on figure 6 a)
Figure 6 a
or fill the pump set with help of the pump (see paragraph: priming
B
of the pump set).
• Open the pump door by pressing up on the lower wall and rotating
the door upwards at the same time (see figure 6 b).
A
• Position the looped section of the silicone tubing around the rotor.
Stretching lightly, (see figure 2a) seat the cassette into the pump
(see figure 2b).
Figure 6 b • Close the pump door.
Switching "ON"
For proper pump operation, make sure the pump door is closed prior
ON/OFF
to switching the pump on. Press the "ON/OFF" key for 2 seconds.
The pump beeps and carries out a short self test, showing the pump
serial number in 8 digits. Verify that all display segments and symbols
are active as shown in figure 7 (see next page).
The pump displays the total volume delivered since the memory was
cleared and switches in the hold mode ready for programming.
Switching "OFF"
Press the "ON/OFF" key and keep it pressed for 2 seconds. A continuous
ON/OFF
alarm will be heard and the pump switches off.
The feeding program (installed parameters) and total volume
administered since the last clearance will be retained in the pump's
memory.
If the pump shuts down due to low battery voltage, the memory will be
retained for 24 hours.
"HOLD" mode
To temporarily pause the pump, or switch into "hold" mode whilst
START/STOP
operating, press the "START/STOP" key once. Three beeps are heard
UK
and the run symbol disappears.
The programmed flow rate (ml/h), volume (VOL=DOSE) and the
administered volume (ml) are retained.
-48-
The "hold" mode is used to temporarily stop the flow of feed:
• to change the feeding program (installed parameters),
• to change the feed container,
• to administer medication without switching the pump off,
• to silence an alarm and correct problems.
After 3 minutes a two tone audible alarm sounds and the message "PUSH STRT" appears in the
display.
Press "START/STOP" to stop the alarm and to extend the hold mode by a further 3 minutes or
press "START/STOP" twice (3 beeps will be heard) to resume programmed settings.
Priming of the pump set
When the pump is in the hold mode:
ON/OFF
Press and hold the "FILL SET" key for 2 seconds to activate the "FILL
SET" maneuver. Release the button as soon as the pump generates a
beep and starts pumping at a flow rate of approx. 600ml/h. During this
FILL SET
maneuver the message "FILL SET" appears in the display. The pump
will automatically stop when the Flocare ® Pack Infinity
completely filled with feed. However this "FILL SET" maneuver can at
anytime be stopped by pushing the "FILL SET" key a second time. The
pump will return to the hold mode when the "FILL SET" maneuver is
complete or stopped.
Display
The pump has a liquid crystal display (L.C.D.) with large alphanumeric characters, smaller
symbols, words and a back light.
The following information can be found in the display:
• Flow rate (ml/h), volume (ml), is displayed through the large characters.
Words below describe what the number relates to (rate, dose or volume).
The pump also displays messages, for example "end of dose" will appear when the pump
has finished delivering a single feed dose.
• The arcs around the run symbol rotate when
the pump is running.
• The remaining battery capacity (see para-
graph: battery operation).
Figure 7
• The wall plug symbol indicates that the
charger is plugged in.
The back light of the display turns off 10 seconds after the last key is pressed.
The back light will switch on for 10 seconds when the charger is connected to the mains.
™ pump set is
UK
