Condition Cause
ERRA- ERRZ • The self test detected • Turn the pump "off", make sure the pump door is
an electronic error closed and switch the pump back "on". If the error
persists, contact your healthcare provider or refer
the pump to service.
No plug symbol • The wall outlet doesn't work. • Connect the pump to another wall outlet.
visible, while the • The adaptor is damaged. • Contact your healthcare professional or
pump is connec- Nutricia subsidiary to replace the adaptor.
ted to the mains.

SET UP MODE

The set up mode is used • to set the alarm level,
• to lock the keypad,
• to switch the audible alarm off when a dose is administered.
• to switch the light of the LCD permanently on when connected
to the mains.
This set up mode may only be entered by healthcare professionals and authorised personnel
trained to use this application of the pump.
The patient or his/her relatives without permission of the physician, dietician, nurse or other
licensed practitioner, may not change the settings of the set up mode.
To set the alarm level
+
+
ON/OFF & Beep high
–
Beep low
2 sec 2 sec
Switch the pump "on" while holding the "+" key down. The pump enters the set up mode.
First the alarm level can be set:
"BEEP HIGH" (+) or "BEEP LOW" (-)
Use the "+" or "-" key to change the setting from "high" to "low" or from "low" to "high".
To lock the keypad
+
Unlock
FILL SET
–
Lock
Press in the set up mode the "FILL SET" key to switch to the next setting:
"UNLOCK" the keypad (+) or "LOCK" the keypad (-). In the "LOCK" mode the feeding program
of the pump can no longer be changed.
Use the "+" or "-" key to change the setting from "lock" to "unlock" or vice versa.
To mute when dose done
+
Beep when done
FILL SET
–
Mute when done
Press in the set up mode the "FILL SET" key to switch to the next setting:
UK
"BEEP WHEN DONE" (+): the pump will give an alarm when the dose is administered or "MUTE
WHEN DONE" (-): the pump will not give an alarm after administering the dose. Use the "+"
or "-" key to change the setting from "beep when done" to "mute" or vice versa.
-54-
To switch light on
Correction
+
FILL SET
–
Press in the set up mode the "FILL SET" key to switch to the next setting: "LIGHT ON" (+) the
light of the LCD remains on when the pump is connected to the mains. "LIGHT OFF" (-) the
light of the LCD switches off after a few seconds even if connected to the mains. Use the "+" or
"-" key to change the setting from "light on" to "light off" or vice versa.
Press the "ON/OFF" key and hold it down for 2 seconds to exit the SET UP mode. The settings
are automatically saved.

TECHNICAL SPECIFICATIONS

• This Flocare
® Infinity
Call are designed to EN 60601-1-2, EN 61000-3-2, EN 61000-3-3, RTCA DO-160D standards
for electromagnetic emissions and immunity and are in compliance with Directive
93/42/EEC.
• IEC 601: Class II
• Microprocessor controlled
• BF Equipment
• Charger: input 100-240V 50-60 Hz minimum current capacity of 0.75 Amp (for 100 V AC)
or 0.35 Amp (for 240 V AC), output 5 V DC 2.4 A
• Battery: internal rechargeable Lithium ion battery, 3.6 V DC 2000 mAh
• Battery capacity: 24 hours at 125 ml/h
• Jet waterproof: IPX 5
• IPX 5: Splash water proof: Water jets from any direction shall have no effect on the pump.
• Dimensions: 140 x 95 x 35 mm
• Weight: approx. 392 g
• Accuracy flow rate: ±5,0% with appropriate Flocare
• Humidity:
• Temperature:
• Atmospheric pressure:
• Occlusion detection pressure: Upstream occlusion:
• Air bubble detection: The amount of air, that must pass the air sensor before the air alarm is
activated, varies from 0.5 to 1 ml which relates to an air bubble with an approximate length
in the silicone pump segment of 6 - 13 cm.
• Normal operation should not interfere with nor be affected by other electronic equipment.
The Flocare ® Infinity
• The use of other accessories, adaptors and cables than listed within this manual may result
in increased emissions or decreased immunity of the equipment of the Flocare
pump.
• To dispose of a pump, please contact your local Nutricia Subsidiary.
light on
ON/OFF
Light off
2 sec
™ pump in combination with the adapter and the Flocare ® Infinity ™ Nurse
0344
Medical Device Directive: Class IIa
® Infinity ™ pump set
Operation mode: 30% to 75% noncondensing
Storage: 10% to 95 % noncondensing
Operation mode: +5°C to +40°C
Storage and transportation: -20°C to +65°C
Operation mode: 70-106 kPa
Storage and transportation: 50-106 kPa
-34 kPa (tolerance 21 kPa)
Downstream occlusion: 83 kPa (tolerane 21 kPa)
™ can safely be operated on commercial aircraft.
® Infinity
UK
™
-55-
