Description of control panel
The ZE4 electric panel is suitable for
controlling the automation of EMEGA
series 230V garage-type doors with up
to 600W power and 50-60 Hz frequency.
Wholly designed and built by CAME
S.p.A., it meets UNI 8612 regulations in
force. ABS Case with an IP54 protective
level, with air recycling inlet and trans-
former.
The circuit requires 230V (a.c.) and the
inlet is protected with two 5A fuses,
whilst the low voltage command devices
are protected by a 2A fuse.
The accessories' total wattage (24V)
must not exceed 20W.
Safety
Photocells can be connected to obtain:
- Re-opening during closure (2-C1), if
the photocells identify an obstacle while
the gate is closing, they will reverse the
direction of movement until the gate is
completely open;
- Total stop (1-2), shutdown of gate
movement without automatic closing; a
pushbutton or radio remote control must
be actuated to resume movement.
N.B : If an NC safety contact (2-C1, 1-2)
is opened, the LED (n°7, pag.8) will flash
to indicate this fact;
- Obstacle presence detection. When the
motor is stopped (gate is closed, open or
half-open after an emergency stop
command), the transmitter and the
control pushbutton will be deactivated if
an obstacle is detected by one of the
safety devices (for example, the
photocells);
Accessories which can be connected
- Courtesy Light. A light that illuminates
the manoeuvring zone; after an opening
command, the light remains on for a
fixed time of 5 minutes and 30 seconds,
connect it to terminal block E1-E3.
GENERAL CHARACTERISTICS
- Open gate pilot lamp . It is a light that
indicates the garage-type door's open
position and turns off when the gate acti-
vates the closing end-stop, connect it to
terminal blocks 10-5;
- 24V electric lock , connect it to terminal
blocks 11-EB.
- Automatic closing. The automatic
closing timer is automatically activated
at the end of the opening cycle. The
preset, adjustable automatic closing time
is automatically interrupted by the
activation of any safety system, and is
deactivated after a STOP command or in
case of power failure;
- "Operator present" . Gate operates only
when the pushbutton is held down (the
radio remote control system is
deactivated);
- Limit switch opening . The door stops
with the help of the microswitch during
the opening phase, connect the
microswitch to terminal blocks F-FA and
switch dip n°9 to OFF;
- Pre-flashing . After an opening or
closing command, the flasher connected
to the W-E1 flashes for 5 seconds before
beginning the procedure;
- Type of command :
-Open-stop-close-stop by button and
transmitter;
-Open-close by button and transmitter;
-Open only by transmitter.
- Operating time;
- Automatic closure time;
- Motor torque device consisting whit a 5
position commutator (p.8, n°10).
Other functions
Adjiustments
Caution! Disconnect the unit from
the main power lines before carrying out
any operation inside the unit.
