SYSTEM LAY-OUT

2
5
4
5
1 - R50 operator
2 - Radio antenna
3 - Blinker
4 - Photoelectric cells (external)
5 - Photoelectric cells (internal)
6 - Key selector

TECHNICAL FEATURES

Gearmotor for operating industrial swing gates with overall maximum weight of
2000 kg.
The R50 is an irreversible electric gearmotor with adjustable drive force, regulated
by changing the pressure exerted by the drive wheels on the ground.
The drive wheels are able to run over surface irregularities of up to 3 cm (approx.),
3
because the gearmotor unit slides along a vertical track. The pressure setting
between the drive wheels and the ground can vary from 30 to 130 kg maximum
and is maintained by an adjustable spring.
6
5

TECHNICAL DATA

Max. leaf length
Max. leaf weight
Average opening time 90°
Max torque
1
6
Operating speed
4
Power supply
Motor capacity
Power absorbed
Capacitor
1
230/50-60 Normative cycles
Daily cycles suggested
Service
5
Consecutive cycles guaranteed
Grease
Actuator weight
Operating temperature
Protection grade
1
Measurements in mm
29
R50
m 10
kg 2000
s 78
Nm 57
m/s 0,180 (50Hz) - 0,216 (60Hz)
230V~ 50Hz 220V~ 60Hz
W 437 511
A 1,96 2,32
µF 16
n° 3 - 78s/2s
n° 300
% 60
n° 4/78s
COMLUBE LHITGREASE EP/GR.2
kg 45
°C -10 ÷ +55
IP 54
G
B
2
