Configuration Display
level
In 2
K1 Switch
K1 Fn
K2 Switch
K2 Fn
Error Time
ErrorAction
TravelTErrFn
TravelLevel
TravelTime
AlarmMaxK1
AlarmMinK1
AlarmMaxK2
AlarmMinK2
CpyParaSet
PwrFailDir
4 SetCalibration X-Direction
W-Direction
W-Function
Set W-free
Y-Direction
Function
Determines the function of the digital input "In 2"
Defines the type of output
Determines the function of output K1
Defines the type of output
Determines the function of output K2
Determines the delay time between error recognition
and error message
Determines the function of the process valve if there
is an error message
Switches on/off valve travel monitoring
Maximum position deviation of the valve
Valve travel time monitoring
Switch point that switches after K1 is exceeded
Switch point that switches after K1 is undershot
Switch point that switches after K2 is exceeded
Switch point that switches after K2 is undershot
Copies parameters to various working memories
(P1/P2/P3/P4)
Defines the function during power failure
Determines the direction of the actual value signal
(rising/falling)
Determines the direction of the set value signal
(rising/falling)
The control curve is defined
10 control curve points can be programmed as
desired
Determines the direction of the process controller
output (rising/falling)
17 / 18
SideStep
Value range
OFF/ON
Safe/ON
ParmSetB0
ParmSetB1
NC / NO
P min
P max
P min/max
W min
W max
W min/max
X min
X max
X min/max
Active
Error
Warning
NC / NO
P min
P max
P min/max
W min
W max
W min/max
X min
X max
X min/max
Active
Error
Warning
0.0...100.0 s
Close/Open/Hold
OFF / ON
0.0...100.0 %
0.0...120.0 s
0.2...99.8%
0.2...99.8%
0.2...99.8%
0.2...99.8%
Close/Open/Hold
rise / fall
rise / fall
Lin./1:25/1:50/free
W 0%
W10%
W20%
W30%
W40%
W50%
W60%
W70%
W80%
W90%
W100% 0...100%
rise / fall
SideStep
®
Positioner
Factory setting
OFF
NO
no
NO
No
0.2s
Close
ON
1.0%
10.0s
10.0%
90.0%
10.0%
90.0%
Close
rise
rise
lin.
0...100% 0.0%
0...100% 10.0%
0...100% 20.0%
0...100% 30.0%
0...100% 40.0%
0...100% 50.0%
0...100% 60.0%
0...100% 70.0%
0...100% 80.0%
0...100% 90.0%
100.0%
rise
®
Positioner
