Configuration
Display
level
2 SetBasics
W-Input
X-Input
Default
SpeedAdj
StartSpOpe
StartSpClo
StopSpOpen
StopSpClo
ForceAdj
InitFOpen
InitFClose
ForceOpen
ForceClose
Init Valve
GoClose
GoOpen
D.Refresh
Dlight
AutoReturn
HelpText
HelpLanguage
3 SetFunction
ProcCtrlMode
ProcCtrl
Proc-P
Proc-I
Proc-D
Proc-T
IxType
IxTime
PosCtrl
Pos P
Pos D
Pos T
MinPos
MaxPos
CloseTight
Open Tight
DeadBand
Digital Input
In W
In X
In 1
Function
Type of set value signal
Type of actual value signal
Reset to factory setting
Submenu for setting the speed
Starting speed direction OPEN
Starting speed direction CLOSED
Stop speed before reaching the OPEN end position
Stop speed before reaching the CLOSED end
position
Submenu for setting the maximum axial forces
Axial force direction OPEN during initialization
Axial force direction CLOSED during initialization
Axial force direction OPEN
Axial force direction CLOSED
Starting initialization
Scanning the closed position
Scanning the open position
Time for display refresh
Setting the display lighting
Time for an automatic return to working level - Setup
Superimposes the help text
Text language
Switch process controller on or off
Submenu for setting process controller parameters
KP-amplification of the process controller
Ti reset time for the process controller
KD share of the process controller
Tv Process controller delay time
Defines the type of actual value filter
Filter time for actual value input
Submenu for setting positioner parameters
P amplification of the positioner
D amplification of the positioner
Decay time of the D share of the positioner
Stroke limitation = lower position of control range
Stroke limitation = upper position of control range
Defines the range that the valve is closed under
controlled force
Defines the range that the valve is opened under
controlled force
Permissible control deviation
Submenu for setting digital inputs
Determines the function of the digital input "In W"
Determines the function of the digital input "In X"
Determines the function of the digital input "In 1"
16 / 18
SideStep
Value range
4-20mA
0-20mA
4-20mA
0-20mA
Yes / No
0.0...100.0%
0.0...100.0%
0.0...100.0%
0.0...100.0%
0.0...55.0%
0.0...55.0%
0.0...55.0%
0.0...55.0%
0.1...1.0s
OnKey / On
1...60min
ON / OFF
D / GB
ON / OFF
0.0...100.0
0.0...999.9s
0.0...100.0
1...10000ms
OFF / RC / avr
0.10...20.00 s
0.0...100.0
0.0...100.0
1...5000ms
0...100%
0...100%
0.0...20.0%
80.0...100.0%
0.1...25%
OFF/ON
Safe/ON
ParmSetB0
ParmSetB1
OFF/ON
Safe/ON
ParmSetB0
ParmSetB1
OFF/ON
Safe/ON
ParmSetB0
ParmSetB1
SideStep
®
Positioner
Factory setting
4-20mA
4-20mA
Yes
100.0 %
100.0 %
10.0 %
10.0 %
45.0 %
45.0 %
45.0 %
45.0 %
0.1s
OnKey
5min
ON
D
OFF
0.5
2.0s
0.0
1000ms
OFF
0.10 s
1.0
0.0
100ms
0.0%
100%
5.0 %
100%
1.0%
OFF
OFF
OFF
®
Positioner
