Install the bracket in the car
1
Remount the L-profile bracket onto the application tool if it has been adapted. Place the
application tool on top of the cross beams and by using the tool ensure that there is suf-
ficient space for Turny Evo paths. Adjust the L-profile brackets laterally where required.
Mark each hole for each mounting leg to be drilled in the L-profile brackets and beams.
Then loosen the L-profile brackets from the application tool and drill.
Spirit level
2
Drill two holes into the side of the L-profile bracket
and two holes in the cross beam for each mounting
leg.
9 mm
Getting seated Turny Evo
Mark where the hole will be
drilled into the L-profile bracket
and the cross beam for all legs.
