3.3 Assignment of DMX channels in overview:

:
3-Channel Mode
Channel
1 0-255
2 0-255
3 0-255
5-Channel Mode:
Channel
1 0-255
2 0-255
3 0-255
4 0-255
5 0-255
7-Channel Mode:
Channel
1 0-255
2 0-255
3 0-255
4 0-255
5 0-255
6 0-255
7 0-10
11-255
Value
H hue (color value) (0-100%)
S saturation (0-100%)
V luminance (0-100%)
Value
Intensity Red, Value within "000" and "255"
Intensity Green, Value within "000" and "255"
Intensity Blue, Value within "000" and "255"
Intensity White, Value within "000" and "255"
Intensity Amber, Value within "000" and "255"
Value
Dimmer: Brightness, Value within "000" and "255"
Intensity Red, Value within "000" and "255"
Intensity Green, Value within "000" and "255"
Intensity Blue, Value within "000" and "255"
Intensity White, Value within "000" and "255"
Intensity Amber, Value within "000" and "255"
No Function
Strobe-Effect, Value within „000" and „255" (0 ... 20 Hz)
Software version of the device
Function
Function
Function
19
You can adjust the power consumption
in the [POW] menu. Power
consumption is approximately 55W in
[NORM] mode and 105W in [HIGH]
mode.
In this version is not activated
