Part 5: Maintenance:

IMPORTANT NOTE: Disconnect the device from the power supply before servicing!
Screws used must be tightened and may not show rust marks. The housing, the mounting bracket and the
mounting location (e.g., ceiling or traverse) may not be adapted, e.g. do not drill additional holes in mounting
brackets, change the connections, etc.
Clean the externally accessible optical lenses regularly to optimize the light output. The frequency of cleaning
depends on the operating environment: damp, smoky or particularly dirty environments can cause a greater
amount of dirt accumulation on the device's appearance.Use a lint-free, moistened cloth for cleaning. Never use
alcohol or solvents for cleaning!

Part 6: Technical Data:

MODEL NAME:
Product type :
IP protection:
Color:
LED Number:
LED Type:
Light output
Beam angle :
DMX Input:
DMX Output:
DMX Modus:
DMX Functions:
Standalone Functions:
Controls:
Displays:
Operational voltage:
Power consumption:
Power supply connection:
Housing material:
Housing color:
Dimensions:
Weight:

Part 7: Environmental protection:

To all residents of the European Union:
This product is subject to European Directive 2002/96 / EC. Dispose of your old device
not with normal household waste.
This symbol on the product or on the packaging indicates that disposal of this product can damage
the environment after its life cycle. Do not dispose of the unit (or used batteries) as unsorted household waste. The
unit or used batteries must be disposed of by a specialized company for recycling. This unit must be returned to
the dealer or a local recycling company. Respect local environmental regulations.
If in doubt, contact your local authority for disposal instructions.
WEEE-Reg.-Nr. Deutschland: DE51964046
IP PAR1818
Outdoor LED Par
IP65
RGBWA
18
12W 5in1
22500lux@1m
25
3-pin Special plug, screwed
3-pin Special plug, screwed
3, 5, 7 or 12 Channels
Color change, color fading, program change, stroboscope, dimmer
Color change, color fade, auto mode, stroboscope, M / S operation
Mode, Setup, Up, Down
4-digits LED Display
110-240 VAC / 50/60Hz
110W
3-Pol Special plug, screwed
Metal
Black
230x320x230mm
6kg
22
(In/Out)
